Product Attribute:
Current:4-20mA
Resistive:10Ω
Output:Digital signal
Size:20inch
Weight :5kg
Color:Blue
Pressure:100KPa
Material:Other
Wiring Type:Other
Applicationt:
ROSEMOUNT
Production Description:
Rosemount 3051S Electronic Remote Sensor (ERS?) System
Featuring best-in-class performance and measurement stability, the Rosemount 3051S Electronic Remote Sensor (ERS?) System is engineered with flexible, digital architecture. The ERS System calculates differential pressure electronically using two pressure sensors linked together with an electrical cable. Easy to install, this safety-certified system is engineered for faster response time than traditional systems, providing you with exceptional performance in a wide range applications.
Our services:
1.We can provide 1-year warranty.
2.The goods will be shipped out within about 3-5 working days.
3.Shipping methods: air by DHL/UPS/EMS/Fedex...
4.Small orders can be all accepted.
5.Contact us any time when you feel free.
Specifications
Accuracy
Up to ±0.025% of span
Warranty
Up to 15-yr limited Warranty
Rangedown
Up to 200:1
Max. Operating Pressure
Up to 10,000psi (689.48 bar)
Process Temperature Range
Based on fill fluid - Maximum 770°F (410°C), Minimum -157°F (-105°C)
Communication Protocol
4-20 mA HART?
Seal System Type
Direct Mount
Transmitter Connection
Welded-Repairable, All Welded
Process Connection
Flanged: ANSI/ASME, EN/DIN, GOST, & JIS
Threaded: NPT, DIN, ISO
Hygienic
Process Wetted Material
316L SST, Alloy C-276, Alloy 400, Tantalum, Gold-plated Alloy 400, Gold-plated 316L SST, see full specs for complete list of materials
Diagnostics
Basic Diagnostics
Certifications/Approvals
SIL 2/3 certified to IEC 61508 by an independent 3rd party, 3A, NSF, NACE?, hazardous location, see full specs for complete list of certifications
Features
Provides DP Level measurements with a faster response time than traditional systems
Sensors are independently installed without heat tracing and insulation to offer simple installation
Digital architecture delivers stable measurement for applications with excessive temperature variation
Each sensor can be independently serviced for simplified maintenance
Entire system utilizes a single 2-wire, 4-20 mA HART? loop for straightforward system integration
Graphical interface of device dashboard offers simple configuration, commissioning and troubleshooting
Additional monitoring information of static pressure and sensor module temperature provide improved process insights
SIL 2/3 certified to IEC 61508 (via 3rd party) and prior-use certificate of FMEDA data for safety installations
