Rosemount 3051CFC Wireless Compact Annubar Flow Meter

Product Attribute:

Voltage:12v

Type:Water temperature gauge

Weight :5kg

Material:other

Applicationt:

ROSEMOUNT

Production Description:

Rosemount  3051CFC Wireless Compact Annubar  Flow Meter
Built with a secure WirelessHART? network, the Rosemount 3051CFC Wireless Compact Annubar Flow Meter provides optimal flow measurement accuracy without the cost of wiring. This device is designed with a patented averaging pitot tube engineered for installation between raised-face flanges, eliminating the need for impulse piping and additional process penetrations. The T-shaped design of this sensor also includes a flat upstream surface for high performance over a wide flow range.



Our services:
1.We can provide 1-year warranty.
2.The goods will be shipped out within about 3-5 working days.
3.Shipping methods: air by DHL/UPS/EMS/Fedex...
4.Small orders can be all accepted.
5.Contact us any time when you feel free.

Specifications

DOWNLOAD FULL SPECS
Measurement Type Differential Pressure
Accuracy Up to ±1.80% of flow rate
Stability Up to ±0.20% of Upper Range Limit (URL) for 10 years
Warranty Up to 5-year limited warranty
Rangedown Up to 150:1 (8:1 flow turndown)
Measurement Range Up to 1000 inH2O (2,48 bar) differential
Line Size 2 to 8 in. (50 to 200 mm)
Output Differential pressure, scaled variable
Communication Protocol WirelessHART?
Process Wetted Material 316 SST
Diagnostics Basic Diagnostics
Certifications/Approvals NACE?, hazardous location, see full specs for complete list of certifications
Update Rate 1 sec. to 60 min., user selectable
Power Module Life Up to 10-year life, field replaceable (order separately)
Wireless Range Internal antenna (225 m)



Features

WirelessHART? technology is secure, cost-effective and delivers >99% data reliability
Compact pitot tube designed to fit and install between raised-face flanges for straightforward installation
T-shape sensor with flat upstream surface offers a fixed separation point for high performance over a wide flow range
10-year stability and 8:1 flow turndown (150:1 rangedown) produce reliable measurements and application flexibility Sensor design eliminates the need for impulse piping and added pipe penetrations for a cost-effective solution
Complete flow assemblies are leak-tested and calibrated to reduce leak points up to 70% and simplify installation
SmartPower? module provides up to 10-year maintenance-free operation and field replacement without transmitter removal
Easy installation enables quick instrumentation of measurement points without the cost of wiring
