Rosemount 2051CFP Wireless Integral Orifice Flow Meter

Product Attribute:

Voltage:12v

Type:Water temperature gauge

Weight :5kg

Material:other

Applicationt:

ROSEMOUNT

Production Description:

Rosemount 2051CFP Wireless Integral Orifice Flow Meter

Featuring a wireless solution with >99% data reliability, the Rosemount 2051CFP Wireless Integral Orifice Flow Meter is an industry-standard flow meter designed with WirelessHART?technology. This device is customized with a primary element that is provided in a meter run and facilitates highly accurate flow measurement in small line sizes (0.5 - 1.5 in. or 15 - 40 mm). This wireless flow meter is easy to install and offers quick commissioning of measurement points without the cost of wiring.


Our services:
1.We can provide 1-year warranty.
2.The goods will be shipped out within about 3-5 working days.
3.Shipping methods: air by DHL/UPS/EMS/Fedex...
4.Small orders can be all accepted.
5.Contact us any time when you feel free.

Specifications

Measurement Type
    Differential Pressure

Accuracy
    Up to ±2.25% flow rate

Stability
    ±0.125% of Upper Range Limit (URL) for 5 years

Warranty
     5-year limited warranty

Rangedown
    Up to 150:1 (8:1 flow turndown)

Measurement Range
    Up to 1000 inH2O (2,48 bar) differential

Line Size
    0.5 to 1.5 in. (15 to 40 mm)

Output
    Differentiual pressure, scaled variable

Communication Protocol
    WirelessHART?

Process Wetted Material
    316 SST

Diagnostics
    Basic Diagnostics

Certifications/Approvals
    NACE?, hazardous location, see full specs for complete list of certifications

Update Rate
    1 sec. to 60 min., user selectable

Power Module Life
    Up to 10-year life, field replaceable (order separately)

Wireless Range
    Internal antenna (225 m)





Features

    WirelessHART? technology is secure, cost-effective and delivers >99% data reliability
    Primary element integrated in a meter run for ease of installation
    Integral orifice plate suitable for small line sizes 0.5- 1.5 in. (15 - 40 mm) for optimal accuracy and repeatability
    Complete flow assemblies are leak-tested and calibrated to reduce leak points up to 70% and simplify installation
    SmartPower? module provides up to 10-year maintenance-free operation and field replacement without transmitter removal
    Easy installation enables quick instrumentation of measurement points without the cost of wiring
