Rosemount 2051L Wireless Level Transmitter

Product Attribute:

paking:new and original

Applicationt:

ROUSEMOUNT

Production Description:

Rosemount 2051L Wireless Level Transmitter

Rosemount 2051L Wireless Level Transmitter provides level measurements with a variety of process connections, materials and WirelessHART?technology. The SmartPower? module of this wireless device provides up to 10-year, maintenance-free operation as well as field replacement. For improved performance over traditional installations, this transmitter has Tuned-System? assembly and direct mounting options.


Our services:
1.We can provide 1-year warranty.
2.The goods will be shipped out within about 3-5 working days.
3.Shipping methods: air by DHL/UPS/EMS/Fedex...
4.Small orders can be all accepted.
5.Contact us any time when you feel free.


Specifications

Accuracy
    Up to 0.05% of span

Warranty
    Up to 5-yr limited Warranty

Rangedown
    Up to 100:1

Max. Operating Pressure
    Up to 300 psi (20,68 bar)

Process Temperature Range
    Based on fill fluid - Maximum 401°F (205°C), Minimum -157°F (-105°C)

Communication Protocol
    WirelessHART?

Seal System Type
    Direct Mount, Tuned-System

Transmitter Connection
    Welded-Repairable

Process Connection
    Flanged: ANSI/ASME, EN/DIN, JIS

Process Wetted Material
    316L SST, Alloy C-276, Tantalum

Diagnostics
    Basic Diagnostics

Certifications/Approvals
    NACE?, hazardous location, see full specs for complete list of certifications

Update Rate
    1 sec. to 60 min., user selectable

Power Module Life
    Up to 10-year life, field replaceable (order separately)

Wireless Range
    Internal antenna (225 m)




Features

    WirelessHART? technology is secure, cost-effective and delivers >99% data reliability
     Tuned-System Level assembly and direct mounting produce optimal performance for level applications
     Optimized seal system construction ensures a quality measurement in harsh process conditions
     SmartPower module provides up to 10-year maintenance-free operation and field replacement without transmitter removal
     Easy installation enables quick instrumentation of measurement points without the cost of wiring
