Product Attribute:
Applicationt:
Kaitai
Production Description:
Sand Blasting Machine
Sand Blasting Pot
Product Features:
The sand blast pot we supply is movable sand blast system with rubber wheels. Widely used in all kinds of sand blast rooms, rooms, and even can be used in large shot blasting chamber as a supplement for the dead angles which a shot blaster cannot reach.
Application:
a sand blast machine can be used for all kinds of metal surface. For example, large industries such as shipbuilding, aircraft, wind power equipment, large oil or gas tanks, containers, locomotives, etc. And also, small industries such as steel structures or castings with complex structures will be suitable for sand blasting.
Classification:
According to the number of guns, there are single gun type, double gun type and three gun type;
According to work efficiency, there are two types of intermittent and continuous.
Parameters as follows for your reference:
model |
Outline sizemm |
Integral volumem³ |
Air source configurationm³/min |
Air pressurempa |
sand blasting capacitykg/h |
Sand blast pipe lengthm |
note |
|
KP-0.1-JX |
720x800x1250 |
0.1 |
6 |
0.5~0.6 |
1800~2100 |
10 |
Single gun+intermittence |
|
KP-0.2-JX |
800x940x1460 |
0.2 |
6 |
0.5~0.6 |
1800~2100 |
10 |
Single gun+intermittence |
|
KP-0.3-JX |
620x940x1900 |
0.3 |
6 |
0.5~0.6 |
1800~2100 |
10 |
Single gun+intermittence |
|
KP-0.5-JX |
720x1060x1900 |
0.5 |
6 |
0.5~0.6 |
1800~2100 |
10 |
Single gun+intermittence |
|
KP-0.5-JX- |
720x1060x1900 |
0.5 |
12 |
0.5~0.6 |
3600~4200 |
10x2 |
Double guns+intermittence |
|
KP-0.7-JX |
820x1200x1900 |
0.7 |
6 |
0.5~0.6 |
1800~2100 |
10 |
Single gun+intermittence |
|
KP-0.7-LX |
820x1200x2200 |
0.7 |
6 |
0.5~0.6 |
1800~2100 |
10 |
Single gun+continuity |
|
KP-0.7-JX- |
820x1200x1930 |
0.7 |
12 |
0.5~0.6 |
3600~4200 |
10x2 |
Double guns+intermittence |
|
KP-0.7-LX- |
820x1200x2200 |
0.7 |
12 |
0.5~0.6 |
3600~4200 |
10x2 |
Double guns+continuity |
|
KP-0.7-JX- |
1170x1280x1780 |
0.7 |
18 |
0.5~0.6 |
5400~6300 |
10x3 |
three guns+intermittence |
|
KP-1-JX |
1120x1460x2400 |
1 |
6 |
0.5~0.6 |
1800~2100 |
10 |
Single gun+intermittence |
|
KP-1-JX- |
1120x1460x2400 |
1 |
12 |
0.5~0.6 |
3600~4200 |
10x2 |
Double guns+intermittence |
|
KP-1-JX- |
1120x1460x2400 |
1 |
18 |
0.5~0.6 |
5400~6300 |
10x3 |
three guns+intermittence |
Sand Blasting Machine
Sand Blasting Pot
Product Features:
The sand blast pot we supply is movable sand blast system with rubber wheels. Widely used in all kinds of sand blast rooms, rooms, and even can be used in large shot blasting chamber as a supplement for the dead angles which a shot blaster cannot reach.
Application:
a sand blast machine can be used for all kinds of metal surface. For example, large industries such as shipbuilding, aircraft, wind power equipment, large oil or gas tanks, containers, locomotives, etc. And also, small industries such as steel structures or castings with complex structures will be suitable for sand blasting.
Classification:
According to the number of guns, there are single gun type, double gun type and three gun type;
According to work efficiency, there are two types of intermittent and continuous.
Parameters as follows for your reference:
|
model
|
Outline sizemm
|
Integral volumem³
|
Air source configurationm³/min
|
Air pressurempa
|
sand blasting capacitykg/h
|
Sand blast pipe lengthm
|
note
|
|
KP-0.1-JX
|
720x800x1250
|
0.1
|
6
|
0.5~0.6
|
1800~2100
|
10
|
Single gun+intermittence
|
|
KP-0.2-JX
|
800x940x1460
|
0.2
|
6
|
0.5~0.6
|
1800~2100
|
10
|
Single gun+intermittence
|
|
KP-0.3-JX
|
620x940x1900
|
0.3
|
6
|
|
