Piled And Released Type Shot Blasting Machine

Piled And Released Type Shot Blasting Machine

Application:  Kaitai

Market Type:  After Market

Packing:  Standard Export Packaging

Samples:  Free

Maximum Prodcution Capacity:  250,000set

Delivery Time:  60 Days

Place of origin:  China

Export Ratio:  41% - 50%

Price Terms:  FOB

Delivery Port:  Qingdao

Minimum Order:  1Set/Sets

Product Attribute:

Applicationt:

Kaitai

Production Description:

  Piled and Released Type Shot Blasting Machine Product Features:
It could be continuous running,it also could be batch or intermittent running. It is flexible production and high productivity.
Casting could pass-through shot blasting zone at lower speed or it will carry out multi position rotation in shot blasting area.It has good cleaning effect.
It could be static loading and unloading material and it is easy for operation.
Production Application:
It mainly used for removing sand and surface cleaning of less variety ,mass production and multi variety, middle-small batch production casting.It is widely used.


Parameter
Unit Q583 Q585 Q5810 Q588
cleaning workpiece size mm 800 x1500 800 x1200 1300 x2800 550 x2200
station No. set 2 4 6 4
blasting wheel quantity kg 4 6 6 4
blasting capacity kg/min 4 x250 6 x360 6 x330 4 x480
blasting wheel power kw 4 x15 6 x22 6x22 4 x22
the max capacity weight of hook  kg 300 500 1000 800
Productivity of every hook h 40 55 50 30
cleaning room size mm 3062 x1800 x2800 8500 x1800 x3885 8500 x2300 x4800 6800 x2600 x3325
total ventilation volume m³/h 15000 18000 18000 17200
total power kw 74.5 186.85 186.85 121.05

 Hanger Type Shot Blasting Machine Shot blasting machine

Product Features:

No fit,compact, high productivity.

Production Application:

It is suitable for surface cleaning of medium-small casting.Sometimes it also replace trolley type shot blasting machine for cleaning bigger casting along with increasing of loading of hook.

Specification: Q376Q378Q3710Q3720Q3730Q3750Q3780

Item

Unit

Q376

Q378

Q3710

Q3720

Q3730

Q3750

Q3780

Diameter of cleaning workpiece

mm

Ø600

Ø800

Ø800

Ø1400

Ø1600

Ø1800

Ø2000

Height of cleaning workpiece

mm

1100

1500

1850

2300

2200

2500

3000

Weight of single hook

kg

600

800

1000

2000
