Product Attribute:
Applicationt:
Kaitai
Production Description:
Trolley Type Shot Blasting Mahcine
Product Features:
Large loading and high coverage rate of shot blasting
Large blasting and high cleaning efficiency
Shot blasting combines with shot peening,it could blast blind zone,cleaning is complete
Economic cleaning for large and heavy castings and forgings
Production Application:
The equipment is suitable for marine engines, energy, power generation components,wind towers, pumps,turbines,machine tools, electrical machinery,chemical machinery,construction machinery and other industries in large, heavy and complex castings, forgings and welding parts.
Specification:Q365CQ3610Q3620Q765CQ7610Q7620Q7630
Parameter |
Unit |
Q365C |
Q3610 |
Q3620 |
Q765C |
Q7610 |
Q7620 |
Q7630 |
|
appearance size of workpiece |
mm |
2500x1300 |
2500x1500 x280 |
4000 x3000 x700 |
2500x1300 |
2500x1500 x280 |
4000 x3000 x700 |
4000 x2000 |
|
max weight of workpiece |
kg |
5000 |
10000 |
20000 |
5000 |
10000 |
20000 |
30000 |
|
blasting capacity |
kg/min |
2 x260 |
4 x250 |
4 x250 |
2 x260 |
4 x250 |
4 x250 |
4 x250 |
lifting capacity of elevator |
t/h |
40 |
60 |
75 |
40 |
60 |
75 |
60 |
|
separatorquantity |
t/h |
40 |
60 |
75 |
40 |
60 |
75 |
60 |
|
ventilation volume |
m³h |
13200 |
240000 |
21000 |
13200 |
240000 |
21000 |
21500 |
|
power( exclude dust collector) |
kw |
39.2 |
188.45 |
185.25 |
39.2 |
188.45 |
185.25 |
83.2 |
appearance size (length*width*height) |
mm |
9000 x4200 x9290 |
14900 x500 x8700 |
16900x6450 x10020 |
9000 x4200 x9290 |
14900 x500 x8700 |
16900x6450 x10020 |
9168x7680 x10874 |
Trolley Type Shot Blasting Mahcine
Product Features:
Large loading and high coverage rate of shot blasting
Large blasting and high cleaning efficiency
Shot blasting combines with shot peening,it could blast blind zone,cleaning is complete
Economic cleaning for large and heavy castings and forgings
Production Application:
The equipment is suitable for marine engines, energy, power generation components,wind towers, pumps,turbines,machine tools, electrical machinery,chemical machinery,construction machinery and other industries in large, heavy and complex castings, forgings and welding parts.
Specification:Q365CQ3610Q3620Q765CQ7610Q7620Q7630
|
Parameter
|
Unit
|
Q365C
|
Q3610
|
Q3620
|
Q765C
|
Q7610
|
Q7620
|
Q7630
|
|
appearance size of workpiece
|
mm
|
2500x1300
|
2500x1500 x280
|
4000 x3000 x700
|
2500x1300
|
2500x1500 x280
|
4000 x3000 x700
|
4000 x2000
|
|
max weight of workpiece
|
kg
|
5000
|
10000
|
20000
|
5000
|
10000
|
20000
|
30000
|
|
blasting capacity
|
kg/min
|
2 x260
|
4 x250
|
