Product Attribute:
Applicationt:
Kaitai
Production Description:
Catenary Type Shot Blasting Machine
Product Features:
Static loading and unloading workpiece,automatic rapid transport, it could realize that workpiece continuous pass-through shot blasting.(Q38 series ) and multi station point workpiece rotation shot blast (Q48 series)
High production efficiency,low cost
Compact structure,easy to operate
The product model is widely.It could be used in different production efficiency requirement and workpiece size.
Modularization design can be integrated into existing production line.It will realize machinery automatic production.
Production Application:
It mainly used for shot blasting and strengthen of mass production medium-small size casting,forging.
Q38,Q48 Series Catenary Type Shot Blasting Machine
Parameter |
Unit |
Q383/Q483 |
Q385/Q485 |
Q4810 |
|
Cleaning workpiece size |
mm |
800 x1200 |
1000 x1500 |
1000 x2500 |
|
Station No. |
/ |
/3 |
/3 |
3 |
|
blasting wheel quantity |
kg |
6 |
6 |
9 |
|
blasting capacity |
kg/min |
x250 |
x250 |
6x250 |
|
blasting wheel power |
kw |
6x15 |
6x15 |
6x15 |
|
the max loading weight of hanger |
kg |
300 |
500 |
1000 |
|
Productivity of every hook |
h |
30~60 |
30~60 |
40~60 |
|
cleaning room size |
mm |
7680x2000 x2900 |
7680x2000 x2900 |
7680x2000x3800 |
|
total ventilation volume |
m/h |
17000 |
19000 |
19000 |
|
total power |
kw |
73.15 |
73.15 |
114.72 |
