| Specification | |
| General | |
| Power Requirement | 10-16V DC |
| Load Impedance | 4 Ω |
| Max. Power Output | 16V / 4*45W |
| Tone Control | +/-12dB (Bass:100 Hz, Treble:10 KHz) |
| Dimensions | Head Unit: 162*178*100mm
Face Panel: 171*16*105mm |
| Weight | 2.15KG |
| Screen Size | 7" |
| Screen Type | Capacitive Digital TFT Touch Screen |
| Screen Resolution | 1024*600 |
| Adjustable Viewing Angles | Yes |
| Button Light | Colorized |
| Operation System | Android 4.4.4 |
| Car Model | Double Din Universial Model |
| Supported Languages | |
| System Languages | Simplified Chinese, Traditional Chinese, English, Danish, French, German, Spanish, Italian, Dutch, Polish, Portuguese, Russian, Turkish, Ukrainian, Korean, Thai, Hebrew and other 60 languages. |
| User Manual Language | English |
| DVD | |
| Region Free DVD Player | Yes |
| Disc Played | DVD-5, CD, CD-R, CD-RW, DVD±R , DVD±RW, VCD, SVCD |
| Video | |
| Video System | AUTO, NTSC, PAL |
| Aspect Ratio | 4:3 box mode / 4:3 panorama mode\16:9 |
| Video Output Level | 1.0 Vp |
| Horizontal Resolution | 1024*600 |
| Audio | |
| Max. Output Level | 1.5V |
| Frequency Response | 20 Hz-20 KHz |
| Signal to noise ratio | 55 dB |
| Separation | 50 dB |
| Audio Mode | Popular, Rock, Jazz, Classic |
| Audio Adjustment | High, Middle, Bass, Subwoofer |
| AUX IN | |
| Supported System | NTSC, PAL, SECAM |
| Input Mode | Rear RCA Port Input |
| Input Channel | Video Input 1, Left Channel Input, Right Channel Input |
| AV OUT | |
| Supported System | NTSC, PAL |
| Output Channel | Video Output 1, Video Output 2, Front Left Audio Output, Front Right Audio Output |
| Output Function | DVD, AUX IN |
| USB & SD | |
| Maximum Capacity | 32GB (the max files in the USB & SD card should be within 4GB) |
| Audio Files | MP3, WMA, WAV, OGG, FLAC, AAC |
| Video Files | MP4, 3GP, SWF, MPG, VOB, MPEG, RMVB, DAT, FLV, RM, AVI, DIVX, WMV, XVID |
| Picture Files | JPG, BMP, PNG, |
| Picture Resolution | 480×320, 800×480 |
| Video Resolution | 480P, 720P, 1080P |
| Display Setup | |
| Display Mode 1 | Manual Adjust the Brightness |
| Display Mode 2 | Day, Night, OFF |
| AM Tuner | |
| Tuning Range | Europe: 522 KHZ~1620 KHZ Russia: 522 KHZ~1620 KHZ
America 1: 520 KHZ~1720 KHZ America 2: 520 KHZ~1620 KHZ
Japan: 522 KHZ~1629 KHZ |
| IF Frequency | 450kHz |
| Effective Sensitivity (-30db) | 30 dB |
| FM Tuner | |
| Frequency Range | Europe: 87.5 MHZ~108 MHZ Russia: 65.0 MHZ~74 MHZ 87.5 MHZ~108 MHZ
America 1: 87.5 MHZ~107.9MHZ America 2: 87.5 MHZ~108MHZ
Japan: 76.0 MHZ~90 MHZ |
| IF Frequency | 10.7 MHz |
| Effective Sensitivity (-20db) | 7dB |
| Signal to Noise Ratio | 60 dB |
| Stereo Separation | 30dB (1 KHz) |
| Frequency Response | 100-5000KHz |
