Product Attribute:
Supply Ability:5000 Piece/Pieces per Month
Delivery Details:3 days after the payment of the car DVD
Production Description:
Xtrons PF84MTV 8"Multi-touch Screen Touch Panel Dual Canbus GPS Navigator Car DVD Player with Screen Mirroring For Volkswagen/Seat/Skoda
Specification |
Model | PF84MTV |
Hardware | MSTAR 2531, 800MHZ/1G ROM/ 256RAM |
Highlight | 1. Eternal & Classic Original User Interface 2. Multi-touch Screen Touch Panel 3. Screen Mirroring Function 4. Dual Channel CANbus 5. New and Improved Design |
Applicable models and years | For Volkswagen: Caddy (2004 - 2012), EOS (2006 - 2012), Golf Plus (2003 - 2012), Golf V (2003 - 2008), Golf VI (2008 - 2012), Jetta (2005 - 2012), Passat (2005 - 2012), Passat CC (2008 - 2012), Scirocco (2008 - 2012), Tiguan (2007 - 2012), Touran (2003 - 2012), WT5 Transporter 2010, WT5 Caravelle 2010, WT5 Multivan (Not Highline Version) 2010
Seat: Alhambra (2013 - 2016), Toledo (2013-2015)
Skoda: Yeti (2013-2015) |
General |
Power Requirement | 10-16V DC |
Load Impedance | 4 Ω |
Max. Power output | 16V / 4*45W |
Tone Control | +/-12dB (Bass:100 Hz, Treble:10 KHz) |
Dimensions | Head Unit: 176 (L) x 147 (W) x 100 (H) mm |
Face Panel: 259 (L) x 30 (W) x 156 (H) mm |
Dimensions | Head Unit: 146*179*100mm
Face Panel: 213*22*133mm |
Weight | 2.25KG |
Screen Type | Multi-touch Screen, Digital TFT Screen |
Screen Size | 8" |
Screen Resolution | 800*480 |
Button Light | Red & Green |
Language |
Menu Language | Simplified Chinese, English, Traditional Chinese, Hebrew, Russian, Italian, French, Spanish, German, Portuguese, Thai, Czech, Arabic, Turkish and Polish. |
User Manual Language | English |
DVD |
Region Free DVD player | YES |
Disc Played | DVD, SVCD, VCD, DVD-5, CD, CD-R, CD-RW, DVD-9, DVD±R, DVD±RW |
Video |
Video System | AUTO, NTSC, PAL |
Aspect Ratio | 4:3 box mode / 4:3 panorama mode\16:9 |
Video Output Level | 1.0 Vp |
Horizontal Resolution | 800x480 |
Audio |
Max. Output Level | 1.5V |
Frequency Response | 20 Hz-20 KHz |
Signal to noise ratio | 85 dB |
Separation | 80 dB |
Sound Mode | Pop, Rock, Classic, Customize, Cinema, Soft, Heavy Metal, Standard |
AUX IN |
Supported System | NTSC, PAL |
Input Mode | Rear RCA Port Input |
Input Channel | Video Inout 1, Left Channel Input, Right Channel Input |
AV OUT |
Supported System | NTSC, PAL |
Output Channel | AV OUT 1 & AV OUT 2, Front Left Audio Output, Front Right Audio Output |
Output Function | DVD, USB, AUX IN |
USB & SD |
Maximum Capacity | 32GB (the max files in the USB & SD card should be within 4 GB) |
Audio Files | MP3, WMA, WAV, AAC |
Video Files | DAT, DIVX, MPEG, RMVB, VOB, XVID, MP4, AVI, 3GP |
Picture Files | JPG |
Supported Video Resolution | 480P |
AM Tuner |
Tuning Range | China: AM: 522 KHZ~1620 KHZ
Russia: AM: 522 KHZ~1620 KHZ
America: AM: 530 KHZ~1710 KHZ
Latin America: AM: 530 KHZ~1720 KHZ
Japan: AM: 522 KHZ~1620 KHZ |
IF Frequency | 450kHz |
Effective Sensitivity (-30db) | 30 dB |
FM Tuner |
Frequency Range | China: :FM: 87.5 MHZ~108 MHZ
Russia: FM1: 65.0 MHZ~74MHZ
FM2: 87.5-108MHZ
America: FM: 87.5 MHZ~107.9MHZ
Latin America: FM: 87.5 MHZ~108 MHZ
Japan: FM: 76.0 MHZ~90 MHZ |
IF Frequency | 10.7 MHz |
Effective Sensitivity (-20db) | 7dB |
Signal to Noise Ratio | 60 dB |
Stereo Separation | 35dB (1 KHz) |
Frequency Response | 30-15000Hz |
Accessories: | 2 x ISO Wiring Harness
1 x USB Adapter Cable
1 x User Manual
1 x Rectifier Filter
1 x GPS Antenna
1 x Radio Adapter Cable
1 x CANbus Box |
Packaging & ShippingStock/ Inventory:
Stock inventory in small quantities are available for delivery at any time.
Shipping Method:
We are direct cooperator with HK DHL/ UPS/ TNT/HK Post and China EMS. Products will delivered to you in the fastest way with the best shipping cost.
Delivery time:For DHL/UPS/TNT, usually it takes 3-5 days to get the shipment delivered. For EMS and post, it depends.
