Product Attribute:
Supply Ability:800 Set/Sets per Month
Production Description:
China 3114 ENGINE CRANKSHAFT 4W3989 4W3579
3114 ENGINE CRANKSHAFT 4W3989 4W3579
Product Description
Specifications For 3114 CRANKSHAFT 4W3989 4W3579
|
Commodity: |
Engine crankshaft |
|
Model: |
3114 crankshaft |
|
Part No: |
4W3989 4W3579 |
|
Vehicle |
3114 |
|
Cylinder dia: |
102.0mm |
|
Packing: |
playwood |
|
Material: |
CAST OR FORGED |
|
Remarks: |
Top quality |
Features for 3114 CRANKSHAFT
1: material was cast or forged.
2: Top Quality, 1 year warranty
3: Fast Delivery & Good packing(harden cartons and plywood)
4: One-step service
Reference Pictures of 3114 CRANKSHAFT
Packaging & Shipping
Shipping
(1): By sea
(2): By air
(3): By express (DHL, FEDEX, TNT, EMS... )
Packing:
(1): TPK packing or nuetral packing
(2): according to your requirments
Our Services
Payment
(1): TT (30 % in Advanced, 70 % before Shipment)
(2): Western Union
(3): Cash
Warranty
All our parts warranty 1 years, If problems from our parts itself, we will take all responsibilty on the spare parts and service.
If the troubles come from human factors, should take responsible for it.
Company Information
Guangzhou TPK Diesel Parts Co.,Ltd, Build in 1996, is a professional manufacturer on Diesel Piston, Piston ring, Cylinder Liner, Head Gasket & Overhaul Gasket Kit. TPK has been cooperating with OEM factory in China for several years, running business mainly in imported diesel engines. All products in TPK have passed the national quality supervision on combustion engines and obtained certificates from ISO9002.
Till now, TPK has four storehouses in Guangzhou, occupying an area of over 5,000 square meters. The number of employees in TPK reaches up to 100, among which include 20 sales personnel in China, 15 sales personnel outside China, 10 QC personnel. TPK products command a ready market in Europe, Middle East, South America, North America, and Southeast Asia and are well received.
With the principles of international brand, good quality, shared resources, and serving the world, TPK endeavors to provide perfect accessories replacement solutions for customers. TPK is ready to cooperte with you to reach a win-win future.
FAQ
Q: Do you have any other engine parts?
A: yes, we have more than 10 kinds of engine repair parts like the followings:
1: Cylinder block, cylinder head, crankshaft, camshaft, connecting rod.
2: Liner Kits. Piston kits, piston ring set, cylinder liner (sleeve), Pin bush.
3: Full / Overhaul gasket kit, head gasket,Oil Seal.
4: Engine bearing, Main bearing, con rod bearing,Camshaft Bearing,thrust washer
5: Engine valve, valve seat, valve guide.
6: Oil Pump, water pump,
7: Starter, alternator
9: Oil cooler, radiator
10: Turbocharger
Q: Do you have Some Other engine models?
A: yes, for C.A.T.E, we have the following models
(1): 3024,3044,3046,3054,3056, 3064, 3066, 3176, 3114, 3116, 3204, 3208, 3126,
(2): 3304,3304PC,3304DI, 3306,3306PC,3306DI, 3406, 3408, 3412, 3508, 3512, 3516,
(3):C2.2, C4.2,C4.4, C6.4, C6.6, C7, C9, C10,C11, C12, C15,C18, C18,C27
(4): D315,D318,D330,D333,D343,D346,D348,D349,D353,D9H,D8,D8H,D8K,G3300,G3406,G3412,G353
Q: Do you have Some Online service?
A: yes, we have Whatspp, Wechat, Skype, YAHOO, QQ...
|
320D |
Crankshaft |
|
|
3066 |
Crankshaft |
5I7671 |
|
3304 |
Crankshaft |
4N7692 |
|
3306 |
Crankshaft |
4N7693 4N7696 4N7699 |
|
3406 |
Crankshaft |
6I1453 |
3114 ENGINE PARTS
ENGINE KITS
KIT Engine kit Call for price and availability
CYLINDER KIT
1077791 Piston skirt 4
PK4P2990 Piston kit 4 Std; 1-pc Aluminum [piston, rings, pin, retainers]
4P2990 Piston body 4 Std; 1-pc Aluminum, Use with ring set 4P6914
PK6I1144 Piston kit 4 Std; 1-pc Aluminum [piston, rings, pin, retainers]
PK6I1144B Piston kit 4 0.50mm; 1-pc Aluminum [piston, rings, pin, retainers]
6I1144 Piston body 4 Std; 1-pc Aluminum, Use with ring set 4P6914
6I1144B Piston body 4 0.50mm; 1-pc Aluminum
PK1014495 Piston kit 4 Std; 1-pc Aluminum [piston, rings, pin, retainers]
PK1014495B Piston kit 4 0.50mm; 1-pc Aluminum [piston, rings, pin, retainers]
1014495 Piston body 4 Std; 1-pc Aluminum, Use with ring set 4P6914 [repl 4P1550]
1014495B Piston body 4 0.50mm; 1-pc Aluminum
PK1051710 Piston kit 4 1051710 piston, rings, pin, retainers
1051710 Piston body 4 Use Ring Set 4P6914
PK7E3428 Piston kit 4 Std; 1-pc Aluminum [piston, rings, pin, retainers]
PK7E3428B Piston kit 4 0.50mm; 1-pc Aluminum [piston, rings, pin, retainers]
7E3428 Piston body 4 Std; 1-pc Aluminum, Use with ring set 7E5213
7E3428B Piston body 4 0.50mm; 1-pc Aluminum
PK7C5668 Piston kit 4 Std; 1-pc Aluminum [piston, rings, pin, retainers]
PK7C5668B Piston kit 4 0.50mm; 1-pc Aluminum [piston, rings, pin, retainers]
7C5668 Piston body 4 Std; 1-pc Aluminum, Use with ring set 7E5213
7C5668B Piston body 4 0.50mm; 1-pc Aluminum
PK9Y7452 Piston kit 4 Std; 1-pc Aluminum [piston, rings, pin, retainers]
PK9Y7452B Piston kit 4 0.50mm; 1-pc Aluminum [piston, rings, pin, retainers]
9Y7452 Piston body 4 Std; 1-pc Aluminum, Use with ring set 7E5213
9Y7452B Piston body 4 0.50mm; 1-pc Aluminum
PK1154124 Piston kit 4 Std; 1-pc Aluminum [piston, rings, pin, retainers]
PK1154124B Piston kit 4 0.50mm; 1-pc Aluminum [piston, rings, pin, retainers]
1154124 Piston body 4 Std; 1-pc Aluminum, Use with ring set 7E5213
1154124B Piston body 4 0.50mm; 1-pc Aluminum
PK1077563 Piston Kit 4 1077563 piston, rings, pin, retainers
1077563 Piston body 4 Use Ring Set 7E5213
7E5213 Ring set 4 Std, [1 cyl set: 1077787, 7E5786, 7C5232]
4P6914 Ring set 4 [1 cyl set: 1077787, 4P1807, 4P1806]
1077787 Ring piston 4 Top chrome [Replaces 1077548, 1051568, 7C0260] [contained in ring sets: 7E5213, 4P6914]
7E5786 Ring piston 4 Intermediate [contained in ring set: 7E5213]
4P1807 Ring piston 4 Intermediate [contained in ring set: 4P6914]
7C5232 Ring piston 4 Oil control [contained in ring set: 7E5213]
4P1806 Ring piston 4 Oil control [contained in ring set: 4P6914]
7C0115 Piston pin 4 For one piece piston
7C3901 Piston pin 4 For two piece piston
7C0111 Retainer piston pin 8 For one and two piece pistons
7C6208 Cylinder liner 4 Repair sleeve
EARINGS
7W9415 Bearing rod pair 4 Std
7C6976 Bearing rod pair 4 .25mm u/s
7C6977 Bearing rod pair 4 .50mm u/s
MS2064P Bearing main set 1 Std; (3)MB3455P, (1) MB3454P, (1) MB3456PF [(3) 1011530, (1) 1077708, (1) 1077602]
1011530 Bearing main pair 3 Std
1077708 Bearing main pair 1 Std
1077602 Bearing thrust pair 1 Std flanged thrust [new# 2124893]
MS2064P25MM Bearing main set 1 .25mm u/s
1450163 Bearing main pair 3 .25mm u/s [repl 7C6971]
1450162 Bearing main pair 1 .25mm u/s [repl 7C6961]
7C6966 Bearing main pair 1 .25mm u/s
MS2064P50MM Bearing main set 1 .50mm u/s
1450165 Bearing main pair 3 .50mm u/s [repl 7C6972]
1450164 Bearing main pair 1 .50mm u/s [repl 7C6962]
7C6967 Bearing main pair 1 .50mm u/s, thrust
2W0027 Bushing con rod 4
2W7211 Bearing cam 1
2W7213 Bearing cam 4
ASKET & SEALS
GASKET NOTE For gasket sets: Call with Serial and Arrangement Numbers
3E7460 Set turbo mounting 1
7X2526 Set turbo mounting 1
7X2523 Set front cover/hsg 1
7X2525 Set rear cover/hsg 1
7X2528 Set water pump 1
1192921 Seal crankshaft front 1 (7C4163)
1154109 Seal crankshaft rear 1 (7C3571)
7C7980 Sleeve crank seal 1 rear
ALVE TRAIN
7W8064 Valve intake 4 [repl 6I1589]
MUI engine
1614280 Valve intake 4 (1136180)
HEUI engine
1360819 Valve exhaust 4 [repl 1051779, 7W2699, 6I1590]
1577126 Valve exhaust 4 (New# 1632432)
7C4273 Valve spring 4 Intake; 2.80 free length
MUI early engines (8) Intake and Exhaust; MUI late engines (4) Intake; HEUI all (4) Intake
6I2307 Valve spring 4 Exhaust, 3.20 length
MUI late engines (4) Exhaust; HEUI all (4) Exhaust
7E7779 Valve spring retainer 8 0.390 height
MUI early engines (8) Intake and Exhaust; MUI late engines (4) Intake; HEUI all (4) Intake
1335037 Valve spring reatiner 4 (repl 4P4949)
MUI late engines (6) Exhaust; HEUI all (6) Exhaust
9Y8848 Valve guide 8
1193036 Valve stem seal 8
1W2715 Valve lock 16
7W8065 Valve insert 4 Intake
MUI engines
1639063 Valve insert 4 Intake
1W2713 Valve insert 4 Exhaust
1193061 Injector sleeve 4 (1193086, 7W5749)
CONNECTING ROD
9N3832 Bolt connecting rod 8
9L7669 Nut connecting rod 8
COOLING SYSTEM
4P3682 Water pump 1 New
7012X Water pump 1 Reman, 4-3/8 pulley; Cast# 4P3681, OEM# 4W0253, 9Y4879
4W0251 Impeller 1
4W0250 Shaft 1
2W0712 Seal 1
7C7890 Pulley 1
3D2824 Seal oring 2
3K0360 Seal oring 3
3J1907 Seal oring 2
3J9671 Seal oring 1
1265869 Thermostat 1 (repl 9Y3365)
1265870 Gasket thermostat 1
4W0549 Gasket thermostat 1
2W7212 Gasket thermostat 1
TURBO / AIR
TURBO TURBOCHARGER New or remanufactured available, call for pricing
Please contact Guangzhou Tpk Diesel Parts Co. , Ltd. to inquing China 3114 ENGINE CRANKSHAFT 4W3989 4W3579
