Product Attribute:
Supply Ability:30000 Piece/Pieces per Month
Delivery Details:5 days
Production Description:
Specifications
Car Monitor
Support 2 cameras input
16:9 wide screen
800 R.G.B x480 dots lcd monitor
RoHS, CE,E-mark,FCC,TS16949 Certificated
6 Inch 4 CH TFT Digital Dashboard HD Reversing Car Monitor for Coach
MDL# | JY-M06 |
Video inputs | 2-CH inputs |
Screen size | 6 Inch Car Monitor |
Type | 16:9 wide screen |
Resolution | 800R.G.B x480 dots |
Color system | AUTO |
Power requirement | 12/32V DC |
Power consumption | ≤8.64W |
Operating temperature | -10°C to +65°C |
MIRROR/NORMAL switch | Yes |
Reversing gear is engaged | Yes |
*Multiple menu languages: English, Dutch, French, Spanish, Russian, German, Italian
*Monitors can be optional with loudspeaker or not, users can adjust sound on the control car monitor
*Support 2 cameras video simultaneous input lcd monitoror
*Support 2 cameras audio simultaneous input lcd monitor
*Can repeat the view picture ,1-60 sec can adjustment car monitor
*Single, dual, triple, quad image for optional car monitor
*Normal or mirrored picture can be switched separately on each camera color monitor
*Separate trigger control wire on each camera rearview monitor
*Monitor will automatic switch- over the image to the corresponding triggered camera and back to the original mode when the trigger stops.
*The trigger delay time can be adjusted (0-4s) on each camera.
*In standby mode, monitor will turn on automatically when triggered and will switch to the corresponding trigger camera image,Trigger end after shutdown
*Working voltage: 12~32V,Self-protect of the DC voltage at the Short-Circuit.
Working voltage: 12V,Self-protect of the DC voltage at the Short-Circuit.
