1.The Specifications of Air-conditioning Compressor Bearing:
1.Air conditioner bearings is a kinds of special bearing for automotive air conditioners, belong to double row ball bearings. This bearings have simple and compact design structure, heavy-load, long-life, high installation precision. At the same time, this type bearings own all the best feature of deep groove ball bearing, such as high precision, low noise, easy installation.
2.Air conditioner bearings are made up of inner ring, outer ring, two sets of balls and two nylon cages. They usually is sealed on two sides and in advance filled the right amount of high performance grease before leave the factory. So they could meet the harsh working environment.
2.The Features of Auto Air Conditioner Compressor Bearing:
Auto air-conditioning compressor bearing,the dominant product or our company,is a kind or fully sealed double row angular contact ball bearing,which is mainly applied to the belt pulley in the auto air-conditioning compressors electro-magnetism clutch,in which has limited space,compact structure as well as light weight,high work temperature and revolving speed and bad work environment,which demand the bearing with the features or heat resistant,long lifetime,low noise,high accuracy,dust-proof.
3.The Prodection of Auto Air Conditioner Compressor Bearing:
1.The installation is correct, that affects precision, life, performance. And fill the bearing with lubricant after installation.
2.Don't allow strong impact, such as hammer striking, transfer roller pressure
3.Use the accurate installation tool, avoid to use cloth kind and short fibers
4.Lubricate the bearing to avoid rust with high quality mineral oil, especially in summer
5.General inspection, such as the surrounding temperature, vibrate, noise inspection
6.Keep bearing cleaning from dirt, dust, pollutant, moisture.
7.Bearing should not be ultra cooled.
3.Auto Air Conditioner Compressor Bearing Catalogue:
|
Auto Air Conditioner Compressor Bearings 35BD219DUM1
|
Item Sizes (mm)
|
Be Used For
|
|
CCF
|
NACHI
|
NSK
|
d
|
D
|
B
|
16
|
|
30BD461816
|
336-2001
|
|
30
|
46
|
18
|
16
|
|
|
30BD4718
|
30BG04S8G-2DS
|
|
30
|
47
|
18
|
|
For SUZUKI DAIHATSU
|
|
30BD472118
|
|
|
30
|
47
|
21
|
18
|
for TOYOTA
|
|
30BD4722
|
30BG4S13-2DST2
|
|
30
|
47
|
22
|
|
|
|
30BD5220
|
30BGS10G-2DST(101.007)
|
|
30
|
52
|
20
|
|
|
|
30BD5222
|
30BGS10G-2DST2
|
30BD5222DU
30BD5222DUUM6
|
30
|
52
|
22
|
|
For FORD , TOYOTA , HONDA
|
|
30BD5523
|
30BG05S5G-2DS
5006-2NSL
30BG05S2DS
|
30BD40DU
30BD219V
|
30
|
55
|
23
|
|
For FORD
|
|
30BD5526
|
30BGS1-2NSL
|
DAC3055CRK
|
30
|
55
|
26
|
|
|
|
30BD6227
|
30BG05S1-2NSL
|
W5206
|
30
|
62
|
27
|
|
|
|
32BD4718
|
32BG04S3G
|
32BD4718DUK
|
32
|
47
|
18
|
|
For AKTI
|
|
32BD522015
|
320-2001
|
|
32
|
52
|
20
|
15
|
For BENZ
|
|
32BD5523
|
32BG05S1 -2DSL
|
32BD45DU
|
32
|
55
|
23
|
|
For MAZDA , XIALI
|
|
35BD5020
|
35BG05S7G-2NST
|
35BD5020DU
|
35
|
50
|
20
|
|
For MITSUBISHI
|
|
35BD5222
|
35BD5222DFX7 (101.006)
|
35BD522DFX7
|
35
|
52
|
22
|
|
|
|
35BD5223
|
35BG05S6G
|
|
35
|
52
|
23
|
|
|
|
35BD5520
|
35BG05S10G-2DST2
|
35BD219DUK
|
35
|
55
|
20
|
|
fOR HONDA , NISSAN
|
|
35BD6224
|
DF0789(101.008)
|
35BD6224DV
|
35
|
62
|
24
|
|
|
|
38BD5417
|
38BG05S2G-2DS
|
|
38
|
54
|
17
|
|
For SUZUKI
|
|
38BD6224
|
101.008
|
|
38
|
62
|
24
|
|
|
|
40BD5524
|
40BGS40G
|
|
40
|
55
|
24
|
|
|
|
40BD572420
|
40BG05S1G-2DS
|
|
40
|
57
|
24
|
20
|
For SANTANA , AUDI
|
|
40BD62206
|
65S7684/6559496
|
40BD49V/90527
|
40
|
62
|
20.625
|
|
For GM(90527)
|
|
40BD6224206
|
40BGS12G-2DS
|
40BD49AWT12DDU
|
40
|
62
|
24
|
20.625
|
For FORD, TOYOTA
|
|
40BD6224
|
40BGS11G-2DS
|
40BD219T12DDU
|
40
|
62
|
24
|
|
For FORD , CHRYSLER
|
|
40BD6624
|
40BGS39G
|
2TS2-DF08A06
|
40
|
66
|
24
|
|
|
|
45BD7532
|
45BG07S5G-2DST
|
|
45
|
75
|
32
|
|
|
|
|
SOLUTION
– At the beginning, we will have a communication with our customers on their demand, then our engineers will work out an optimum solution based on the customers’ demand and condition.
PRODUCTION
– Running in accordance with ISO 9001 quality system, the advanced production equipments, sophisticated processing technology, strict quality management system, skilled workers and innovative technical team, make our bearings in continuous quality improvement & technology development.
QUALITY CONTROL (Q/C)
- In accordance with ISO standards, we have professional Q/C staff, precision testing instruments and internal inspection system, the quality control is implemented in every process from material receiving to products packaging to ensure our bearings quality.
PACKAGE
– Standardized export packing and environment-protected packing material are used for our bearings, the custom boxes, labels, barcodes etc. can also be provided according to our customer’s request.
LOGISTIC
– Normally, our bearings will be sent to the customers by ocean transportation due to its heavy weight, airfreight, express is also available if our customers need.
WARRANTY
– We warrant our bearings to be free from defects in material and workmanship for a 12 months period from the shipping date, this warranty is voided by non-recommended use, improper installation or physical damage.
|
|
|
|
High Quality Bearings, Choose Saifan.
Jinan Saifan Bearing Co., Ltd is a professional bearing manufacture located in Jinan, Shandong.
We are established in year 2005 and we have 10 years experience in bearing manufacture.
We mainly produce wheel hub bearings, ball bearings, roller bearings etc.
|
|
Q:What’s your after-sales service and warranty?
A: We promise to bear the following responsibility when defective product is found:
1.12 months warranty from the first day of receiving goods;
2. Replacements would be sent with goods of your next order;
3. Refund for defective products if customers require.
Q:Do you accept ODM&OEM orders?
A: Yes, we provide ODM&OEM services to worldwide customers, we are able to customize housings in different styles, and sizes in different brands, we also customize circuit board & packaging box as per your requirements.
Q:What’s the MOQ?
A: MOQ is 10pcs for standardized products; for customized products, MOQ should be negotiated in advance. There is no MOQ for sample orders.
Q:How long is the lead time?
A: The lead time for sample orders is 3-5 days, for bulk orders is 5-15 days.
Q:Do you offer free samples?
A: Yes we offer free samples to distributors and wholesalers, however customers should bear freight.
We DO NOT offer free samples to end users.
Q:How to place orders?
A: 1. Email us the model, brand and quantity, consignee information, shipping way and payment terms;
2. Proforma Invoice made and sent to you;
3. Complete Payment after confirming the PI;
4. Confirm Payment and arrange production.
|
