Product Attribute:
Filter level:Pre Filter
Material:Fiber glass
Standard or Nonstandard:Standard
Applicationt:
automobile manufacturer
Production Description:
Product Description
welding fume extractor
Introduce :
Available for both one/single arm and double arms.
The welding fume extractor is easy of installation, and has no technical requirements when the customer install and use it. The flexible extraction arm is made from high quality material of PVC and steel wire, which is anti-corrosion, heat-resistant of up to 140°C. It can swivel 360º and can be brought in any desired direction without additional support. It is equipped with the damper to adjust the wind. It is equipped with the caster wheels and can be freely mobile to meet the requirements of different work places.
The purified gas can meet the standard requirements and can enter into work room or indoor place, which is helpful to keep the room close, maintain the temperature and be convenient for work.
Application :
Used for purification of the smoke and dust during the welding, polishing, cutting, grinding process and the recycling of rare metals and precious material, can purify large amounts of suspended small metallic particles in the air.
Operating Principle:
It is equipped with three layer filter system
1, under the help of the fan device, the welding fume is sucked into inlet through sucking hood. There is the flame arrester in the inlet, so the spark can be blocked here, the left fume and dust is sucked into gravity separator, and then the bigger particles firstly descend into dust bag.
2, the smaller particles are arrested in the surface of core filter. The cleaner gas then flow into clean room after being purified by core filters.
3, in clean room, the clean gas is then further purified by active carbon. At last, the gas meets the required standards and enters into air or other required room.
As a result, all of our replacement elements are manufactured rights here in China, under the most rigorous quality standards. Additionally, all of our filter elements carry Seven ISO Standards and we fully guarantee all of our products.
Q3: How do you guarantee the after-sale service?
A: Before shipment, our products are checked one by one. If any problems caused by the product itself, we will supply you the new replaced ones.
Q4: Do you accept OEM?
A: Yes, we can manufacture according to your requirement.
Q5: Can you design filters according to the working condition?
A: Yes. We have professional R&D department , and we can design the more suitable filters for you.
