Ridge Cap Roll Forming Machine

Product Attribute:

Length:6.2m

Width:1.1m

Height:1.55m

thickness0.3-0.5mm:Coli materialPPGI

shaft material45#steel:The bearing capacity of manual decoiler5 tons

numbers of forming steps11 stations:transmissionchain transmission

Forming speed2-3m/min:main motor power3kw

voltage380V50HZ Three-phase:cuttingHydraulic cutting

Applicationt:

Required

Production Description:

1.The Main ComponentsManual decoilerMain forming machinePLC control systemHydraulic pump stationPost cutElectric motorOutput table
2.The Parameters
1.Model No. Ridge cap roll forming machine
2.thickness:0.3-0.5mm
3.Coli material:PPGI
4.The bearing capacity of manual decoiler:5 tons
5.shaft material:45#steel
6.Out diameter :60mm
7.numbers of forming steps:11 stations
8.transmission:chain transmission
9.Forming speed:2-3m/min
10.main motor power:3kw
11.voltage:380V50HZ Three-phase
12.dimension:6.2*1.1*1.55
13.cutting:Hydraulic cutting
14.blade material:Cr12 steel with quenched treated 60-62°c
15.control system:PLC(Delta)
16:length tolerance:±2mm
17.weight:4.8t
18.spare parts1 easy damaged parts: conk 2pcs, fuse-link 4pcs2 rubber mat: 1 pcs3 bolt spanner: 1 pcs
