Product Attribute:
Supply Ability:10000 Piece/Pieces per Week 28TAG001 bearing
Production Description:
515058 Front Wheel Hub Bearing for Chevy :
Description of the bearing :
The release bearing is a bearing fixed on the shaft going into the gearbox it is movable along it. It is operated when you push clutch pedal to floor and cause the clutch mechanism to operate thus stopping driving force from engine being carried through to gears.
When a clutch friction disc is worn it can slip causing a nasty smell. This is a very 'clingy' and obnoxious smell of burnt material.
Most clutches are self adjusting so w e don't tend to notice it needs replacing until we find we have to let pedal 'all' the way up before it then bites. if we find under hard acceleration engine revs blip or rise before car speed follows? Often with a burning smell.. This is a sure sign clutch is worn out.
Whenever we change a clutch we should change entire assy including release bearing ats ame time false economy not to. Any clutch or release bearing changes require gearbox out of car.
Advantage of clutch bearing
sometime called the (Throw-out bearing)As its name implies, this is the bearing that releases the clutch. It is often referred to as a "throw-out" bearing. They come on a number of different style carriers. The carriers, in some cases, vary considerably with the particular engine. Because the release bearing only works when the clutch is being released it usually lasts quite a long time. However, improper linkage adjustment or riding the clutch with your foot when driving can wear the bearing prematurely. Normally there should be a minimum of 1/16" clearance between the face of the bearing and the three release fingers or diaphragm spring of the pressure plate when the clutch is engaged. This fact is important and will be discussed further when we get to the part about setting up the clutch linkage.
clutch wheel hub bearing catalog :
|
Model |
d,D,C(B) |
Type |
|
513093 |
43x83x27.5 |
Automotive bearing |
|
513098 |
43x83x27.5 |
Automotive bearing |
|
513104 |
37x71.6x52 |
Automotive bearing |
|
513119 |
33x72x59 |
Automotive bearing |
|
513125 |
37x79x45 |
Automotive bearing |
|
513135 |
40x84x26.6 |
Automotive bearing |
|
513155 |
34.5x70.95x47.6 |
Automotive bearing |
|
513200 |
45x70.6x47 |
Automotive bearing |
|
515000 |
45x64.38x51 |
Automotive bearing |
|
515004 |
55x92.35x49.2 |
Automotive bearing |
|
515005 |
55x78.3x74.5 |
Automotive bearing |
|
515008 |
45x73.35x53.2 |
Automotive bearing |
|
515017 |
55x89.85x49.1 |
Automotive bearing |
|
515021 |
58x129x54.5 |
Automotive bearing |
|
515024 |
55x78.3x56.7 |
Automotive bearing |
|
515025 |
58x129x54.5 |
Automotive bearing |
|
515026 |
45x71.85x56.2 |
Automotive bearing |
|
515027 |
45x71.85x56.2 |
Automotive bearing |
|
515031 |
55x92.35x49.2 |
Automotive bearing |
|
515035 |
55x78.3x50 |
Automotive bearing |
|
515038 |
55x78.3x50.7 |
Automotive bearing |
|
515039 |
55x78.7x50.7 |
Automotive bearing |
|
515041 |
58x116.6x68.3 |
Automotive bearing |
|
515048 |
58x116.6x68.5 |
Automotive bearing |
|
515054 |
55x78.3x49.8 |
Automotive bearing |
|
515055 |
58x116.6x68.5 |
Automotive bearing |
|
989012 |
58x121x75.5 |
Automotive bearing |
|
31226776671 |
42x64.1x44 |
Automotive bearing |
|
31262950 |
41x63.5x61.5 |
Automotive bearing |
|
31280051 |
31x63.5x63 |
Automotive bearing |
Toyota:
OE: 44TKB2805, 68TKB3506AP 31230-36150, FCR54-15/2E, 31230-35070, 31230-35090, RCT356, SA9 31230-35090, 40TRBC07-27SB 90363-40022, RCT282SA 70144, CBU442822, 90363-40010, 052TRBC09-7 90363-52001 90363-52086, 50SCRN31P-1 31230-12140, 44TKZ 2801BR, 68SCRN46P-2 31230-36160, 31230-60120
Isuzu:
OE: 54TKA3501 4N35 5-31314001-0, 48TKA3214 8-94101243-0, RCT45-4S, 45TMK804, 24TK308B2U3, 48RCT3301, TK45-4 90363-45002, 78TKL4001
Mazda:
OE: FCR50-10-1/2E E301-16-510, FCR50-17-8/2E, FCR54-46-2/2E H606-16-510, E84-16-510, RCT331SA1 E301-16-510, FCR54-50-1/2E, OK2A1-16-510, B315-16-510
MITSUBISHI:
OE: RCT371SA2 ME602710, FCR55-1/2E MD703270, FCR55-17-11/2E MD719469, 48TKA3210 MD702570, 58TKA3703B ME605584, 65TMK20, 60TMK20, CT70B, CBDSS 3227 MRI95689, 48TKA3201, ME706180
Nissan:
OE: 40TRK-1 RCT4075-1S 30502-21000, 62TKA3309, FCR62-32--14/2E, FCR62-24
Suzuki:
OE: 23265-77500, CT38-1L1, RCTS338SAI, 47RCT3001, FCR50-30-2 50TKE3301
Volkswagen:
OE: 113 141 16513 F-203222.5, F-201769
Daewoo:
OE: 445 237 BE 1#90250658, SNRVALEO BB 12620 S15 &, 50TKA3805 90251210, 96564141
Peugeot:
OE: SASIC-France, 445329AC VKC2216, 2041.67, 2041.23, VKC-2051, VKC 2240,
VKC 2080
Model No.: VKC 2191, VKC2115, GC3P-11-53, 4540357
We also supply other Auto Spare Parts
-Wheel Bearings
-Wheel Hub Assemblies
-Clutch Release Bearings
-Truck Wheel Bearings
Packing details
1.tube+outer carton
2.polybag+single box+carton
3.polybag+single box+wooden case
4.polybag+wooden case
5.As your requirement
Shipping Methods
1. DHL,UPS,TNT,Fedex,Singapore EMS etc.
2. By sea or as your requirement
Payment Term:
1.L/C at sight
2.Telegraphic Transfer
3.Paypal
4.Western Union
5 As your requirement
Our Factory:
Jinan Ruihode Bearing Co.,ltd is a professional bearing manufacturer. We are engaged in the production of quality bearings, such as NSK,NTN, NACHI, KOYO and IKO bearings. We can supply various kinds of bearings according to customers' requirements. Our products enjoy great popularity in the worldwide markets, like Asia, Europe and the USA.
Our products include Taper roller bearings, Deep groove ball bearings, cylindrical roller bearings, Spherical roller bearings, Thrust ball bearings, Spherical thrust roller bearings and Excavator bearings. Products are extensively used in machinery, excavator, hydropower, engineering, railways, automobiles, electric power, textiles, metallurgy, mine, papermaking, sports equipment and precision instruments
Company inspecter will check the products one by one before we sent it out, and we also follow customers' special requests to control the quality. We have got little feedback of quality issue from customers these years. So please rest assure
Why Choose Jinan Ruihode Bearing Co.,ltd
1. We have our own factory,
2.Good material used and Promise working life one year at least.
3. Professional R&D and 100% finished product check before shipment
4. ISO 9001:2000
5. 24 hours aftersale service
FAQ
this price is just for reference , please contact staff to inquiry the specfic price !
