Product Attribute:
Supply Ability:1000 Piece/Pieces per Month
Place of Origin:Zhejiang China (Mainland)
Brand Name:AR2000-02 power window regulator MIDCOOL
Model Number:AR2000-02 power window regulator
highest working pressure:1.0 MPa
joint thread:G1/4
valve type:with overflow
ensured pressure resistance:1.5mpa
pressure regulating range:0.05-0.85mpa
pressure gauge size:G1/8
weight:0.27
bracket:B220
pressure gauge:G36-10-01
Delivery Details:0 days
Production Description:
AR2000-02 power window regulator
Please note that we are selling factory direct products. All our products are 100% brand new in manufacturer's packaging.
Specification:
| Ensured Pressure Resistance | 1.5MPa(15kgf/cm) |
| Highest Working Pressure | 1.0MPa(10kgf/cm) |
| *Pressure Regulating Range | AR1000:0.05-0.7 MPa(0.51-7kgf/cm2)
AR:2000-5000:0.05-0.85 MPa(0.51-8.5kgf/cm2) |
| Ambient and Fluid Temperature | 5-60C |
| Valve Type | With Overflow |
| Model | Specifications | Accessories |
*Rated Flow
(L/min) | Port Size) | Pressure Gauge Size(G) | Weight
(kg) | Bracket | Pressure Gauge |
| AR1000-M5 | 100 | M5 | 1/16 | 0.08 | B120 | G27-10-R1 |
| AR2000-01 | 550 | 1/8 | 1/8 | 0.27 | B220 | G36-10-01 |
| AR2000-02 | 1/4 |
| AR2500-02 | 2000 | 1/4 | 1/8 | 0.27 | B220 | G36-10-01 |
| AR2500-03 | 3/8 |
| AR3000-02 | 2500 | 1/4 | 1/8 | 0.41 | B320 |
| AR3000-03 | 3/8 |
| AR4000-03 | 6000 | 3/8 | 1/4 | 0.84 | B420 | G46-10-02 |
| AR4000-04 | 1/2 |
| AR4000-06 | 6000 | 3/4 | 1/4 | 0.94 |
| AR5000-06 | 8000 | 3/4 | 1/4 | 1.19 |
| AR5000-10 | 1 |
Description:
·
Air Treatment Units are auxiliary components in pneumatic automation system, they are mainly used for treating air source from air compressor, making the air clean dry with stable pressure and lubricated.· The Air Treatment Unit have the functions of air filter, air regulator and air lubricator.· Pull the relief valve and rotate it , then the compressed air pressure can be adjusted to the expired pressure gradd, and can make the pressure pulse balanced, press down the knob to lock it.· Pneumatic Filter Air Source Treatment. to reduce pressure of air which come from air pressure machine, to provide pressue gauge clean and good air.· Combination air filte come with a pressure gauge, easy to use, combination can provide more quickly clean air than simple one.
A Series Air Units are similar to SMC A series Air Preparation units and are our most popular style air units with higher flow rates,simple assembly and maintenance reduces down time.A series Air Treatment Units are available for 8 sizes options from M5 to 1 to ensure optimum performance,offering energy savings,A series Air Treatment Units are a good replacement for SMC Air Units,Air Filter+Air Lubricator+Air Regulator.
AC FRL(AC1000~AC5000)
AC FR+L (AC1010A~AC5010A)
AW Filter Regulator (AW1000~5000)
AF Filter (AF1000~AF5000)
AR Regulator (AR1000~AR5000)
AL Lubricator (AL1000~AL5000)
* Clean looking, modular design
* Energy saving with high flow rate
* Compact spacer with bracket reduces total assembly space
* Optional pressure gauge,body size
* Rc(PT), G(PF) or NPT threads, port sizes: M5, 1/8"~1"
* Optional drain model
* Custom requirements
