Injector OYGAS I03

Product Attribute:

Typical Clients:

NISSAN BYD

Production Description:

Injector for CNG/LPG Conversion Kit, ECE 110R,67R certificate approved

Precisely control gas discharge rate, applying to liquefied petroleum gas and compressed nature gas. Body made of shaped, blue anodized aluminium alloy lightened for better  heat exchange. Plunger made of the special soft iron and was treated by the special process which greatly improved the internal flow dynamics. The type includes1-cylinder, 2-cylinders, 3- cylinders, 4-cylinders, 6-cylinders and many others. Applying to variety of engines.   Technical specifications: Frequency: 0~160HZ Working pressure: 0.05~0.2MPa Max pressure: 0.3Mpa Coil resistance: 3.0ohm±15% Supply voltage: 12VDC±15% Minimum injection pulse: 3.3ms±5% Complete opening/closing time:Tested at: 0.1Mpa     pressure, 12V, 5ms total injection time Opening:3.7ms±5%  closing:2.6ms±5% Temperature: -20°C~+120°C Inlet gas fitting: rubber hose 10mm Outlet gas fitting: rubber hose5mm
