OEE W446 triplex mud pump can 100% interchangeable with Emsco F500 triplex mud pump. It has small volume, low HP, and can fit small diesel engine. It can drill Well below the 3000 meters.
Rated input power:328KW/440HP
Rated Stroke 320 stroke per minute 320spm
Stroke :152.4mm6
Gear Ratio:4.578:1
Max. operating pressure:35Mpa
Valve over valve:API4#
Dia. of Suction manifold:6 150# flange
Dia. of Discharge manifold:3 900#flange
Dia. pinion shaft:95.25 3.75
Key: 22.174x15.9mm
Dimension not including base:2479x1219x1103mm
Weight : 4463kgs
