Product Attribute:
Usage:automobile
Size:40mm*72mm*37mm
Car Make:Renault,Peugeot,
OE NO.:7703090313
Place of Origin:Shandong China (Mainland)
Brand Name:KDKD,Other
Model Number:DAC407237
Warranty:1 Years
Material: Gcr-15 steel, chrome steel, carbon steel
Precision Rating:PO,P6,P5
Hardness:59-63
Clearance:CO,C1,C2,C3,C4
Weight:0.59kg
Processing Customized:Yes
Seals Type:Close C
Main Market:Europe, Southeast Asia, the Middle East, etc
Quality standard:ISO9001
Name: DAC40720037
Production Description:
Double Row Taper Roller Bearing 1H0407625
- Wheel Bearing
- TOPRAN: 103 037
- SEAT: 1H0 407 625
- VW: 1H0 407 625
| - per axle: 2
- Inner Diameter: 40 mm
- Outer Diameter: 72 mm
- Fitting Position: Front Axle left and right
- Width: 37 mm
|
Product Overviews
Wheel hub bearing unit is in the standard angular contact ball bearings and tapered roller bearings, on the basis of it will be two sets of bearing as a whole, has the assembly clearance adjustment performance is good, can be omitted, light weight, compact structure, large load capacity, for the sealed bearing prior to loading, ellipsis external wheel grease seal and from maintenance etc, and has been widely used in cars, in a truck also has a tendency to gradually expand the application.
Products Show:
Company Information
Liaocheng City Kaidi Auto Bearing Co.,Ltd specializes in producing various auto bearings. The main products are automotive wheel hub bearings, automotive air-conditioning compressor bearing, automobile gearbox bearings, automotive differential bearings, automobile engine bearings, automobile steering bearings, automobile release bearings, automotive tension pulley bearings, double row angular contact ball bearings, inch tapered roller bearings, low noise deep groove ball bearings and all kinds of non standard bearings. The company has formed one-stop production system, including lathe processing, heat treating, grinding, and assembling. It is located at Yandian bearing industrial district of Linqing City, Shandong Province and has very convenient transportation.
Welcome friends from home and abroad to visit our factory to negotiate and cooperate.
Auto Wheel Hub Bearing NO.
| Bearing Ref. | d | D | B | Mass(kg) |
| 25BWD01 | 25 | 52 | 42 | 0.36 |
| 27BWD01J | 27 | 60 | 50 | 0.36 |
| 28BWD03A | 28 | 58 | 42 | 0.4 |
| 28BWD01A | 28 | 61 | 42 | 0.53 |
| 30BWD08 | 30 | 55 | 26 | 0.26 |
| 30BWD01A | 30 | 63 | 42 | 0.55 |
| 30BWD04 | 30 | 68 | 45 | 0.69 |
| 32BWD05 | 32 | 72 | 45 | 0.8 |
| 34BWD04B | 34 | 64 | 37 | 0.82 |
| 34BWD11 | 34 | 64 | 37 | 0.46 |
| 34BWD10B | 34 | 66 | 37 | 0.51 |
| 34BWD07B | 34 | 68 | 42 | 0.64 |
| 34BWD09A | 34 | 68 | 37 | 0.54 |
| 35BWD19E | 35 | 65 | 37 | 0.48 |
| 35BWD07 | 35 | 68 | 30 | 0.48 |
| 35BWD07A | 35 | 68 | 30 | 0.48 |
| 35BWD16 | 35 | 68 | 36 | 0.48 |
| 35BWD06A | 35 | 72 | 31 | 0.55 |
| 36BWD04 | 36 | 68 | 33 | 0.48 |
| 36BWD03 | 36 | 72 | 42 | 0.68 |
| 36BWD01B | 36 | 72.041 | 34 | 0.57 |
| 37BWD01 | 37 | 74 | 45 | 0.79 |
| 38BWD19 | 38 | 70 | 37 | 0.48 |
| 38BWD21 | 38 | 70 | 38 | 0.57 |
| 38BWD09A | 38 | 71 | 30 | 0.5 |
| 38BWD22 | 38 | 71 | 39 | 0.62 |
| 38BWD12 | 38 | 72 | 33 | 0.56 |
| 38BWD04 | 38 | 72.041 | 34 | 0.55 |
| 38BWD01A | 38 | 74 | 33 | 0.6 |
| 38BWD06D | 38 | 74 | 50 | 0.82 |
| 38BWD10B | 38 | 74 | 40 | 0.69 |
| 38BWD15A | 38 | 74 | 33 | 0.61 |
| 38BWD24 | 38 | 74 | 33 | 0.62 |
| 38BWD23A | 38 | 76 | 43 | 0.82 |
| 38BWD18 | 38 | 80 | 33 | 0.79 |
| 39BWD03 | 39 | 68 | 37 | 0.5 |
| 39BWD01L | 39 | 72 | 37 | 0.6 |
| 39BWD05 | 39 | 74 | 39 | 0.66 |
| 40BWD06D | 40 | 74 | 40 | 0.66 |
| 40BWD12 | 40 | 74 | 42 | 0.71 |
| 40BWD15A | 40 | 74 | 36 | 0.62 |
| 40BWD16 | 40 | 74 | 34 | 0.59 |
| 40BWD05 | 40 | 76 | 38 | 0.7 |
| 40BWD08A | 40 | 76 | 33 | 0.61 |
| 40BWD07A | 40 | 80 | 34 | 0.73 |
| 40BWD14 | 40 | 80 | 34 | 0.77 |
| 42BWD12 | 42 | 76 | 33 | 0.65 |
| 42BWD06 | 42 | 76 | 35 | 0.64 |
| 42BWD09 | 42 | 78 | 38 | 0.72 |
| 42BWD11 | 42 | 80 | 45 | 0.9 |
| 42BWD13 | 42 | 80 | 34 | 0.76 |
| 43BWD12A | 43 | 76 | 43 | 0.71 |
| 43BWD08 | 43 | 79 | 38 | 0.77 |
| 43BWD13A | 43 | 79 | 45 | 0.87 |
| 43BWD03 | 43 | 80 | 45 | 0.91 |
| 43BWD06B | 45 | 82 | 45 | 0.94 |
| 45BWD06 | 45 | 83 | 45 | 0.95 |
| 45BWD03 | 45 | 84 | 39 | 0.88 |
| 45BWD07B | 45 | 84 | 40 | 0.89 |
| 45BWD09 | 45 | 84 | 40 | 0.9 |
| 45BWD10 | 46 | 84 | 45 | 0.98 |
| 46BWD01A | 48 | 79 | 45 | 0.79 |
| 48BWD01 | 49 | 89 | 42 | 0.9 |
| 49BWD02 | 49 | 84 | 50 | 1 |
| 49BWD01B | 49 | 88 | 46 | 1.05 |
Packaging & Shipping
1. Industrial packaging :Polybag + White Box + Carton + Pallet ,
2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets
3. As the clients' requirements
