Product Attribute:
Place of Origin:Guangdong China (Mainland)
Brand Name:OEM
Model Number:EF-M43B
Type:Interior Mirror
Function:2 ways AV Inputs/Bluetooth/Touch Panel
Screen Size:4.3inch
Screen type:16:9
Signal system:PAL/AUTO/NTSC
Installation :OEM replacement bracket style
Monitor Brightness:300cd/m2
Power sypply:DC12V
Resolution:480(w)RGBX234(H)
Video:2 WAYS AV INPUTS
warranty:2years
Production Description:
It is a multi-functional car mirror integrated with auto dimming, compass,temperature and 3.5"rearview mirror & OSD parking data and built-in buzzer. It needs a bracket to match your car model and replace your original car rearview mirror. It is a better safeguard for your driving safety.
Specifications & Main functions:
•They are "hands off", no manual adjustments are required leaving the driver free to watch the road;
•High Reflectance>70%. Low Reflectance 6~10%;
• 3.5" TFT-LCD car mirror for DVD/VCD;
•Operating Voltage DC 9.0 -16.0 V ;
•Maximum Current <450 milliamps;
•Operating Temperature -40°C ~ +85°C;
•Storage Temperature -40°C ~ +100°C;
• Reflectivity can be changed according the linear changes, which ensure the best visual effects for driver;
• Driving directions can be automatically displayed;
• Inner and out cars temperature display;
• When drived backing cars, it will automatically show the distance and rearview image and are equipped with a bi-bi alarm by built-in buzzer;
•Time to change reflectance from 55% to 15% <6.0 seconds;
•Time to change reflectance from 15% to 55% <8.0 seconds;
•Compass display would be switched to temperature display after pressing O button at 3 seconds, then if you want to see compass display, pls operated as same before;
•Press O button, auto-dimming function is started and Led green indicator lights up. Auto-dimming function is close when press O button again and Led green light is off;
• When reverse gear is engaged,the system automatically switches from auto-diming to backup camera video,and when out-off reverse gear,it switches back automatically;
• When drived backing cars, it will be automatically showed 3 colors indication when nears to obstacles, bi-bi alarm will be made by built-in buzzer;
• 2 way video input;
•Can conncted to DVD/VCD/TV/GPS etc. video input device;
Description:
Panel: TFT LCD (Digital)
Power Supply: DC12V
Screen Size: 4.3
Brightness: 300cd/m2
Resolution: 480*272
OSD Menu: Available
Aspect Ratio 16:9
Signal System: PAL/AUTO/NTSC
Power Consumption: 3.6W(Working) 0.3W (Standby)
Two Video Inputs:AV1-DVD etc.AV2-Camera
Quality Policy:
1. Technic innovation, first high quality, and the uppermost client
Based on its “Customer First” focus, innovate continuously, to satisfy and exceed the customers’ requirement.
2. Execute fully Quality System
Adhering the “Quality First” principle, satisfying all the clients and company members’ need, and achieving the long time
successful management.
3. Continuous reformation, self-improvement
Do analysis internal to improve quality management. Improve continuously, to meet customer's need.
Delivery time:
Sample in 1-3 working days.
100-500pcs in 7-10 working days.
1000pcs in 20 working days
Payment Methods:
Accept Paypal, Western Union, T/T,
