EPS Torque Sensor For BYD

Typical Clients:

Zhuzhou Elite Mechanical Co. Limited

Production Description:

The torque sensors are used in the automotive EPS system. When the steering system is working, the input axle and the output axle rotate. Then torque of the axle makes the slider move in the axle direction. The control arm of the sensor turns the movement of the slider into rotating angle and output relative voltage signal to let the control unit judge the rotating direction of the steering wheel and the steering angle.

Operating Characteristics
Effective Electric Angle:0° to 45°
Effective Mechanical Angle:0° to 87°
Rotation Direction:CW or CCW
Rotation Torque:20Nmm to 45Nmm
Total Resistance:1000Ω
Independence ±1%
Endurance: 3 Million
