fully automatic plastic machine

Applicationt:

Universal

Production Description:

1)automatic plastic machine
2)Center input die head
3)eliminating knit line
4)PLC+touch screen
5)saving-energy

Automatic plastic  machine YJB60-1LII

Main Parameters

Unit

YJB60-1LII

Max. Product Volume

(L)

1

Dry Cycle

(pcs/h)

900×2

Screw Diameter

(mm)

60

Screw L/D Ratio

(L/D)

24

Screw Drive Power

(KW)

15

Screw heating Power

(3ΦW)

6.5

Screw Heating Zone

(Zone)

3

HPDE Output

(kg/h)

70

Oil Pump Power

(KW)

5.5

Clamping Force

(KN)

40

Mold Stroke

(mm)

138-368

Max. Mold Size

(W×H)(mm)

300×320

Max. Die Diameter

(mm)

100

Die Heating Power

(4ΦKW)

1.8

NO. of Heating Zone

(Zone)

3

Blowing Pressure

(MPa)

0.6

Air Consumption

(M3/min)

0.5

Cooling Water Pressure

(MPa)

0.3

Water Consumption

(L/min)

50

Machine Size

(L×W×H)(m)

2.7×1.9×2.6

Machine Weight

(Ton)

4.3
