JQX-40F(JQX-52F) relay

Applicationt:

auto

Production Description:

POWER RELAY WITH COVER,UP TO 40A

Features:
1) Outline dimensions: 74.0 x 47.0 x 47.0mm
2) Contact data:
a) Contact arrangement: 1Z(1C,1H)
b) Materials: silver alloy
3) Max. switching current: 40A
4) Max. switching voltage: 28V DC / 250V AC
5) Max. switching power: 1.12KW / 10kVA
6) Rated load (resistive): 1Z:28VDC/40A 250VAC/40A
                           2Z:28VDC/40A 250VAC/40A
7) Coil data:
a) Nominal voltage: 6 - 220V DC / 6 - 380V AC
b) Picd-up voltage: AC≤75%, DC≤90%
c) Drop-out voltage: DC≥10%, AC≥30%
d) Coil power: 3.5W / 5.5VA
8) Specifications data:
a) Contact resistance: ≤50mΩ
b) Insulation resistance: ≥500mΩ
c) Dielectric strength Vr.m.s:
i) Between open contacts: ≥1,500V AC
ii) Between coil and contacts: ≥2,000V AC
iii) Between contacts form: ≥2,000V AC
d) Ambient temperature: -45 - +55°C
e) Operation/release time: ≤20/20ms
