Big Power Relay(JQX-62F 2Z)

Applicationt:

auto

Production Description:

As a manufacturer and exporter of various relays, we are sure that you will get better products here.

Features:

Model: JQX-62F 2Z
1) Outline dimensions: 95 x 70x 67mm
2) Contact data:
a) Contact arrangement: 2Z(2D 2H)
b) Material: silver alloy
3) Max. switching current: 80A
4) Max. switching voltage: 28V DC / 250V AC
5) Coil data:
a) Nominal voltage: 6 - 220V DC / 6 - 380V AC
b) Pick-up voltage: AC≤90%, DC≤75%
c) Drop-out voltage: DC≥10%, AC≥30%
d) Coil power: 20.W / 2.5VA
6) Specifications data:
a) Contact resistance: ≤50mΩ
b) Insulation resistance:≥500MΩ
c) Dielectric strength Vr.m.s:
i) Between open contacts: ≥1,500VAC
ii) Between coil and contacts: ≥2,000VAC
iii) Between contacts form:
d) Ambient temperature: -45 - +55oC
e) Operation/release time: ≤20/20ms
