Applicationt:
Universal
Production Description:
This product is punched or cut from reinforced expanded graphite sheet, with excellent corrosion resistance.
This product is punched or cut from reinforced expanded graphite sheet, with excellent
corrosion resistance.high and low temperature resistance, good compression
resilient and high intensity. All kinds of circular, complicated geometric gaskets
are widely used in pipes, valves, pumps, pressure vessels, thermal exchangers,
condensers, engines, air compressors, exhaust tubes, and refrigerating machines.
FEATURES:TYPE 95939593/18 9593/1P 9593/689593/6P
material of hoop 08F 304 316 304 316shape of hoop corrugated plate flatbed flatbed corrugated plate corrugated platetemperature °C -200~+450 -200~+600 -200~+650 -200~+600 -200~+650 pressure Mpa 11.0 11.0 11.0 11.0 11.0 PH 0~14 0~14 0~14
1) Perfect sealing performance
2) Low pre-tightening stress, not adhere on flange sealing surface, easy installation,
and low labor force required
3) The gaskets can be made with SS inner or outer eyelet
packing
Inner packing:
Bag
Outer packing:
Carton or wooden case
