American SAE J1508 hose clamp[e-Catalog]

Product Attribute:

Thickness:0.6mm

Bandwidth:12.7mm

Standard or Nonstandard:Standard

Applicationt:

Universal

Production Description:

1,Brand : American Murray clamp
2,100 years' experience
3,Standard : SAE J1508
4,High quality Right price Short delivery

1,bandmm Thickness:0.6mm
2,diameter :18-32mm
3, Free torque : 0.68N.M Ultimate torque6.8 N.M
4,Material: Stainless steel200/300/316

 The Clamps material different, its corrosion resistance is also different. Customers can choose a
suitable hose clamps, according to their practical application.

 EHxxEHxxSSEHFxxSSEHLxxSSMaterial for BandAISI 200 Series SSAISI 200 Series SSAISI 300 Series SSAISI 316 SSMaterial for HousingAISI 200 Series SSAISI 200 Series SSAISI 300 Series SSAISI 316 SSMaterial for ScrewCarbon SteelAISI 200 Series SSAISI 300 Series SSAISI 316 SSDetailHeat-treated,   double-plated with zinc plus trivalent chromate.   corrosion resistanceordinarygoodbetterbestRated Ultimate Torque50in.lbs. min.(5.6Nm)60in.lbs. min.(6.8Nm)60in.lbs. min.(6.8Nm)60in.lbs. min.(6.8Nm)Recommended Installation Torque30-40in.lbs.(3.4-4.5Nm)35-45in.lbs.(4.0-5.1Nm)35-45in.lbs.(4.0-5.1Nm)35-45in.lbs.(4.0-5.1Nm)
