Production Description:
1, Voltage Input: DC8 V～32V
2, Voltage Output: DC12V, Max current output 1A
3, Video input: 4- Way/ 2- Way/ 1way, 1. 0Vp- P，75Ω ，BNC
4, Audio output: 1way, 1. 0Vp- P，75Ω ，BNC
5, Standard: PAL / NTSC, Users can set up
6, Audio Input: 2- Way, Linear input, 50 ~ 4000mv, 50Hz ~ 3500Hz
7, Audio ouput: 1way
8, Compression: MPEG2
9, Video Quality: Maximum resolution: 704 × 576, Frame rate: 25 frames / Sec (PAL), 30 frames / Sec (NTSC)
10, Hard disk: Support for the notebook hard drive (2. 5 inch)
11, Alarm Input: 4- Channel alarm input
12, Alarm Output: 2- Channel alarm output
13, Network: 10/ 100M Base- T, RJ45, Ethernet interface
GPS：NMEA 0183
14, GPRS / GSM: 4- Band, 850/ 900/ 1800/ 1900 MHz (only applies to support GPRS models)
15, Cloud Mirror control: Rs485
16, Language: Chinese / English
17, Product Dimensions: 180mm (L) × 180mm (W) × 42mm (H)
18, Power consumption: 10 watts or so (when the hard disk with about 15 watts)
19, Weight: 2. 8kgs
20, Operating temperature: 0 ℃ ~ +50 ℃, Humidity: < 90%
21, The use of MPEG2 video compression, High- Definition, Full real- Time video
22, Single DVD video can be achieved when the effect of (a resolution of 704x576), Four- Way video at CIF (352x288) results;
23, Maximum support for four- Way video, Two- Way real- Time audio video synchronization;
24, Support wide voltage input DC range of 8V to 32V can be stable. 12V or 24V vehicle power supply may apply
25, When reverse polarity power input, The automatic protection features to protect the video recorder and battery from damage
26, Recorder for each camera input all the way to provide a stable 12V power supply, With power output short- Circuit alarm function, Safe and reliable
27, Startup can be set from time to time, Time off, Saving the use of battery
28, By the vehicle ignition switch control switch machines, And have turned off the ignition delay signal control function
29, Automatic video recording can be set up boot
30, Support Timing video
31, To support the alarm triggered video, Can be set to automatically open the door video
32, Support for video motion detection alarm
33, Earthquake floating box to protect the hard disk
34, In- Line Pin Hard Drives connection box stable and reliable hard drive to avoid the general use of point contact box connection problem caused by poor contact.
35, The use of a drawer- Type hard disk box, Support for 2. 5- Inch notebook hard drive
36, Compatible with FAT32 format hard disk, Hard disk data can be read directly on the computer
37, The use of multiple protection and automatic backup of the file system error correction MPFS, Can avoid the greatest degree of damage or directory 0 track damage caused by the loss of a disk file problem
38, Can simultaneously display and record speed and license plate number
39, 6- Channel sensor signal input can be synchronized with the record show that the braking, Steering, Road status, Such as whistle- Ming
40, Alarm function with speeding
41, Video signal trigger with reversing switch function
