Cummins INLINE 5
Production Description:
Cummins INLINE 5
Product Description:
Supports SAE J1708/J1587 and J1939/CAN data links
Supports USB full speed port at up to 2M baud rate
Supports RS-232 PC/PDA serial port at up to 115.2k baud rate
Is fully compliant with TMC's RP1210 standard
Small enough to fit in pocket
Aluminum housing provides ruggedness
Derives 8 V to 50 V DC power from vehicle
Includes advanced processor for maximum speed and performance
Internal Flash memory allows firmware upgradeability
Includes 5 LEDs to indicate power and USB, RS-232, J1708/J1587, and J1939/CAN communications
Certified to meet European CE requirements
Rated for -40° to +85° C operating temperature
INLINE 5 meets Cummins in-cab environmental test requirements
INLINE 5 product kit (P/N 4918416) includes:
INLINE 5 data link adapter (P/N 3165033)
USB 2 meter cable (P/N 4918419)
DB25F/9-pin data link cable (P/N 3165159)
DB25F/6-pin data link cable (P/N 3165160)
INLINE 5 software CD (P/N 4918417)
Storage case (P/N 3165143)
