GASOLINE GENERATOR DATA

Product Attribute:

Applicationt:

GASOLINE GENERATOR DATA Gasoline Generator Data Set Type XGGF3500E Rated Frequency HZ 50 Rated Output Power KVA 2.8 Maximum Output Power KVA 3.2 Rated Voltage V 230 Rated Current A 12.2 Rated Speed r (min 3000 Generator Generator Type KT-3 Pole Number 2 Phase Number Single Excitation Mode Self Excitation Power Factor COSΦ 1.0 Insulation Class B Engine Type XG178FG Cylinder Type One Cylinder, 4 stroke, Air cooled, Direct Injection Bore×Stroke mm 78×62 Gross Displacement ml 296 Compression Ratio 20∶1 Rated Power KW 3.68 Lubrication method Pressure Spray Lubrication Type CD30 Lubrication Capacity L 1.1 Starting method Recoil hand starting or Electrical Starting Star Motor Capacity V-KW 12V 0.8KW Charge Alternator Capacity V-A 12V 3A Accumulator Capacity×Number V-Ah 12V 36Ah Fuel Type Gas Fuel Consumption Rate g)

Production Description:



















  GASOLINE GENERATOR DATA

Gasoline Generator Data
Set Type				XGGF3500E
	Rated Frequency		HZ	50
	Rated Output Power		KVA	2.8
	Maximum Output Power		KVA	3.2
	Rated Voltage		V	230
	Rated Current		A	12.2
	Rated Speed		r/min	3000
Generator	Generator Type			KT-3
	Pole Number			2
	Phase Number
