Product Attribute:
Applicationt:
LICARDO Diesel Generator Set 24GF
Production Description:
LICARDO Diesel Generator Set 24GF
Diesel Generator Set Dat
Standby Power:24KW/30KVA
Prime Power:22KW/27KVA
Rated Current:39(A)
Rated Frequency:50Hz
Start-up time:56s
Power Factor:0.8Lag
Rated Voltage:400/230V
Standard Features
Engine:LICARDO K4100D
Radiator 50 max
Fans are driven by belt, with safety guard
24V charge alternator
Dry type air filter, fuel filter, oil filter
Alternator: single bearing alternator
IP22, insulation class H/H
Main line circuit breaker
Standard control panel
Absorber
Muffler
User manual
Diesel Engine Data
Manufacturer:LICARDO Engine Co
Model:K4100D
Prime /Standby Power:0KW/33KW
Rated Speed:1500r/min
Cycle:4 stroke
Cylinder Arrangement:4 in line
Displacement:3.61L
Bore and Stroke:100*115mm
Compression Ratio:19:1
Governor Type:Mechanical
Start battery voltage:24V DC
Air Intake System
Air Intake System:Naturally aspirated
Max Intake Restriction:6.1kPa
Burning Capacity:6.2m3/min
Air Flow:168m3/min
Exhaust System
Exhaust Gas Flow:12.2m3/min
