Baolong
Cut to length line ECL series A cut to length line is generally used for jobs like uncoiling, straightening, measuring, cross-cutting to length and stacking of various materials such as cold or hot rolling carbon steel, tinplate, stainless steel, and other kinds of metal with coated surfaces.
Features of Cut to Length Line: 1. This cut to length line uses a roll feeding, AC servo drive. 2. It has a fully digital length control system that ensures fast positioning with little error. 3. It has a hard chrome plated surface and is durable and abrasion resistant. 4. It is used together with a hydraulic shear or an air-clutch shear to carry out fast shearing and convenient clearance adjustment. 5. This cut to length line is suitable for hot rolling carbon steel, tinplate, stainless steel, and other kinds of metals with coated surfaces.
Model
Coil thickness(mm)
Coil width(mm)
cut tolerance(mm)
Line speed(max)(m/min)
Shear number(max)(spm)
Coil weight(ton)
ECL-2X1300
0.2-2
300-1300
±0.3
60
50
7/15
ECL-2X1600
400-1600
ECL-2X1850
900-1850
40
20
ECL-3X1600
0.5-3
15
ECL-3X1850
ECL-3X2000
900-2000
45
30
ECL-6X1600
1-6
600-1600
±1
25
ECL-6X2000
ECL-8X2000
2-8
ECL-12X2000
3-12
±1.5
10
ECL-16X2000
4-16
±2
8
