Product Attribute:
Output Power:-kw
Length:-mm
Width:-mm
Height:-mm
Output voltage:-V
Output current:-A
rated oil pressure:10mpa
theoratical pressure:48kn
Hydraulic Riveting Machine max stroke:140mm
daylight opening height:250mm
Hydraulic Riveting Machine throat depth:250mm
Hydraulic Riveting Machine down speed:100mm/s
pressing speed:10-50mm/s
return speed:100mm/s
the height of the working table:900mm
the height of the bed:600*400mm
Hydraulic Riveting Machine motor power:2.2kw
riveting motor power:1.5kw
spindle motor speed:10-1400rpm
Hydraulic Riveting Machine weight:650kgs
Applicationt:
High-quality Sevro Hydraulic Riveting Machine press forming, bending, punching, stamping, stretching, press fit and shaft alignment and etc You can also log into our website for more information kindly checking. Website: E-mail:fangbocn1@gmail.com
Production Description:
New machine,C frame Sevro Hydraulic Riveting Machine,
Non-standard plan can be customized according to customer's demand
FBY-XHC480
Product feature1.With C-type machine body design, machine body is integrally cast to ensure good rigidity, small deformation through high temperature aging treatment.2.It is specially designed for edge forming, riveting operation for various accessories, for example, auto steering gears and silicone-oil clutches etc. 3.With power head design, principal axis is driven to rotate by serve motor, and can stop at any required position. Rotary speed of principal axis can be adjusted freely, with easy operation and large actuating range. 4.Adoption of all hydraulic system ensures high pressure, stable operating performance, large pressure adjustment range and high accuracy.5.With safety design and double-hand operation, the machine is furnished with functions of emergency stop and up-and-down inching.6.Deep-throat type hydraulic riveting machine is appropriate for products with comparatively large external structure. 7.Movable workbench (push cylinder) can be installed to ensure loading and unloading of materials are conducted within safety area outside riveting head in order to guarantee safety of operators. 8.Principal axis has two kinds of speeds, fast stepping and pressurized slow stepping when moving downwards. Fast stepping improves operation efficiency. The speed of pressurized slow stepping can be adjusted freely to protect molds and improve riveting quality of products.9.Adopt two kinds of circulative starting modes, manual button and pedal. 10.Products within wide diameter range can be riveted. Products of different diameters can be riveted by adjusting the opening of spin riveting head. Replacement of riveting mold is easy. 11.Infrared safety device (Optional upon customers requirements).12.Spin riveting head is furnished with protective cover to ensure safety of operators. 13.Torque testing device can installed on special machine (auto steering gear).
