Product Attribute:
Voltage:0~40kv
Applicationt:
Unversal
Production Description:
Launch EA2000 Engine Analyzer
EA2000 is an engine analyzer developed for the test of vehicle engines and electric control system. The innovative device is capable of testing the working conditions, operation parameters and emission performance, as well as acquiring the primary and secondary ignition signal, injection signal and electric sensor signal in real time. The analyzer can carry out performance analysis, store, bring up and print out test results in support of the diagnosis on the engine. The test results can be used in determining the technical status and finding problems with the engine.
Feature
Gasoline engine
Test and data analysis of primary/secondary ignition waveform, spark energy and waveform characteristics at conventional ignition
Test and data analysis of primary/secondary ignition waveform, spark energy and waveform characteristics at single-cylinder (independent) ignition
Test and data analysis of primary/secondary ignition waveform, spark energy and waveform character Specification
Parameter Range Precision
RPM 0~8000rpm 1%
Ignition ADV 0~60° ±1°
Ignition voltage 0~40KV 5%
Spark voltage 0~4000V 5%
Ignition duration 0.04~9.99ms 0.04ms
Cranking current 0~900A 5%
