Glass Laser Marking Machine

Glass Laser Marking Machine

Application:  Acura ( Tsx(china)) Acura ( ...

Market Type:  After Market

Packing:  wooden case

Delivery Time:  15-20 working days

Place of origin:  China

Price Terms:  FOB

Delivery Port:  Shanghai

Payment Terms:  T/T

Applicationt:

Acura ( Tsx(china))
Acura ( Tl(china), Rsx(china), Rl(china), Mdx Trims(china), Mdx, Rl, Tl)

Production Description:

Product Features
1. Clearly marking logo, company name and series numbers on glass
2. Can mark 0.01-0.2mm
3. Automatically increase serial numbers
4. High speed scanner and extender focus system, high marking precision.
5. Permanent marking effect to avoid being erased


Technical Parameters
(The working area and laser power can be customized according to requirement)


Model of Machine		 CX-CO2-30/60/80(optional)
Foci 275mm(optional)
Laser tube Co2 laser tube
Cutting Area 110mm×110mm /300mm×300mm(optional)
Laser Power 30W/60W/80W (optional)
Marking Speed 0-7000mm/s
Operating Voltage AC220V±10%,50HZ
Location Precision ±0.01mm
Working environment Temperature: 5-35centidegree, Humidity: 0-95%
Min. line width 0.015mm
Min. character 0.3mm
 Graphic Format Supported BMP, HPGL(PLT), JPEG, GIF, TIFF, PCX, TAG, CDR, DWG, DXF,compatible HPG order, support DXF, PLT, BMP and DXT(Tiandao embroider software),etc.
Marking depth 0.01-0.2mm
Working Table Lift platform up to 1,000mm from the bottom to the top
Auxiliary device exhaust fan and cooling system
Laser Wavelength 1064nm

Applicable materials or industries
Glass tube, glass ceiling, glass jar, glass rod, glass ware, lamp bulb, glass crafts, glass bottle and other glass material products.

Package:
Wooden case

After sales service
1. The whole set of machine is guaranteed for one year, not including normal replacement of wearing parts.
2.User-friendly English manual and Video CD for machine using and maintaining.
3. Our self-developed English software can do all kinds of pattern recognition
