IK44 Mechanical Fuel Diesel Flow Meter

Product Attribute:

Certification:CE

MinimumFlowRate:20lpm

MaximumFlowRate:120lpm

Applicationt:

china coal

Production Description:

chinacoal12
m.chinacoalintl.com Italy K44 Mechanical Fuel Diesel Flow Meter, Fuel Diesel Flow Meter,Flow Meter   Product Details Basic Info. Model NO.:K44
Type:Mechanical Flow Meter
Measuring Principle:Mechanics
Measuring Media:Liquid
Certification:CE
Accuracy:>± 1%
Measurement Object:Closed Pipeline
Application:Industrial Production
Size:DN10-50
Main Application:Diesel Fuel
Sensor:Tube/Flange
Color:Red , Black
Export Markets:Global
  Description:

K44 flow meter is a nutating-disk meter that measures the exact quantity of the dispensed fuel or lubricant. It is designed for non-commercial use only. This flow-meter is reliable, inexpensive, easy to install and simple to calibrate on the workplace. The Pulser model is fitted with a pulse emitter for connection to a fuel management system.
Thanks to reduced flow resistance, it can also function by gravity.

Specifications:

Flow-rate (range): 20÷ 120 l/min (5, 3÷ 32 gal/min).
Precision: ± 1% of flow range after calibration.
Repeatability: 0, 2%.
Max. Operating pressure: 10 bar (142 psi).
Bursting pressure: 30 bar (426 psi).
Readout system:
K44, 4-digit subtotals (max 9999 litres), 7-digit totals.
Resolution: 0.1 litre.
Pulser card type: "Open collector", frequency: 10 pulses/litre, power supply: 6-24 V DC, max 10 mA.
