12ch Smart Dimmer Pack ZL-1205

Product Attribute:

Typical Clients:

USA

Production Description:

Product name: 12ch smart dimmer pack
Product numberZL-1205
Product features:
1This dimmer pack is a 12ch smart dimmer pack, with high speed CPU memory do the mathematic operation .
2Every channel has circuit breaker.against overloading .LCD display.
3When it is used as a DMX pack, it can be controlled by 1-12 ch. Channel address can be set between 001-512.
4)  3 pin male XLR socket for DMX input, 15PIN D socket for analog DC 0-10V input
51-12 built-in programs. Speed preset.
6Analog input. This product can be controlled by 12ch DC 0-10V signal.
7Every channel can be operated separately and has linear dimming from 0-100%.
8Many functions: Preheat, Power failure memory, phase correction ,DMX signal parallel , stand alone.
9Rating current: 6.3A/ch, 75A totally
10Single phase input AC 220V/50~60HzThree phase input  AC 220V/50~60Hz
11)  Rating current for every channel :10~20Atotal 60~120A
12)  Single phase input AC 220V/50~60HzThree phase input  AC 220V/50~60Hz
Packing Size (mm)530×480×190    1PCS/CTN
NW9.2KgS         GW:  11.7 KgS
Dimension(mm)482 x 400 x 176        1PCS/CTN
