Australian Standard Spray Booth/Paint Room[e-Catalog]

Application: surface painting

OEM No/Model: EZ-YB100R

Market Type: After Market

Maximum Prodcution Capacity: 196sets/month

Place of origin: China

Minimum Order: 1Set/Sets

Language Translator

Product Attribute:

Applicationt:

surface painting

Production Description:

Australia spray booth, paint booth

Detailed Product Description
Infrared Light Heater Down Draft Spray Booth WD-70A with EPS material
Automobile Maintenance Baking, Drying, Auto Spray Booths And Repair Painting Room

1. White, orange. Blue
2. For automobile
3. Complete steel assemble Basement and floor

Car painting, Automobile Baking, Portable Auto Spray Booths
1. Italian Riello RG5S diesel burner
2. SUS304 Stainless steel heat exchanger
3. Anti-flame and Heat-Insulation

1) For car painting and baking
2) maintains a high level of safety and performance together with top quality construction and materials
3) Various systems of environmental protection are optional for customers
4) A wide range of colors available: White, red, marine blue, gray, orange
5) Trustworthy durability of each parts
6) Good after-sales service

Packaging & Delivery

Packaging Detail: Export professional packages. Our packages are professional. We use the iron bracket package and it can fix the products and prevent them from broken. Moreover, we will label every components and it is easy for the customers to distinguish
Delivery Detail: To effect shipment within 7 days after deposit

For more information please email

Inside Dimension	6900X3900X2600MM(LXWXH)
Outside Dimension	7000X5200X3250MM(LXWXH)
Main door	3-fold, 2700X2500MM(WXH) with heat insulation glass window, aluminum alloy door frame
Personal door	1-fold, 650X1800MM(WXH) with one step. There is two sets of pressure lock which will automatically open when the pressure inside is over the limit
Booth System	Wall panel: EPS material, tongue and groove interlock construction, thickness: 50mm, 0.5mm steel plate.
Booth System	Basement and floor: complete steel assemble, 2 rows of grids, 2 rows of indentedplates, galvanized. 2pcs of galvanized ramps, loading capacity of galvanized grating is 650 kg/wheel, 700X1800mm(WXL)
Lighting System	Ceiling light: 4Pcs X8units=32PcsX36W, with electronic ballast
Glass	All window and light cover by ovenproof toughened glass
Generator setting type	Back upper intake air, back upper exhaust air, aluminum alloy frame, coated steel
Ventilation System	Intake fan: 1Pc turbo fan, 7.5KW motor, direct drive, air capacity:25000m3/h Exhaust air system optional
Heating system	10 units infrared curing lamps for heating, 3 lamps/uts, each lamp 1KW, total power 30KW.
Filter system	Prefilter, high efficiency filter EU5 Fine Filters, 6pieces (ceiling filter), floor filter, exhaust active carbon filter
Control system	Spraying, baking temperature, time setting, lighting switch, failure alarm, thermostat, power supply switch, emergency stop.
Total power	39KW
