Product Attribute:
Power:16kw
Voltage:110/220/380v
External Size:7000*5350*33000mm
Internal Size:6900*3900*2650mm
Air Volume:26000m3/h
Color:Blue
Front Door:3000*2600mm
Basement:3 rows of diamond plate 2 rows of grilles
Wall Board:50mm EPS panel double 0.376mm steel
Lighting:Ceiling 8units*4
Heating:Italy Riello G20
Applicationt:
For all Types of Car
Production Description:
Model NO.
EZ-YB 100R
Sketch |
|
|
Outside Size(mm) |
7000x5350x3300 |
Inside Size(mm) |
6900x3900x2650 |
Front Door(mm) |
3000x2600(WxH) |
Total Power |
16kw |
|
Basement |
=1.0mm galvanized steel for bottom coaming, the floor beam is made of galvanized square tube whose specification is 40mmx80mmx1.8mm; 3 rows of diamond plate, 2 rows of grilles, made by 30mmx4mm flat steel, then paint. =2.75mm diamond steel plate to make 2 embossed steel ramp, 1 piece stairs. The whole structure is strong, durable and beautiful. |
|
Cabin System |
50mm EPS panel, double 0.376mm steel with tongue and groove structure. The main door is without aluminum side cover, produced by one-time suppress. The watching window is with 5mm white glass. Aluminum alloy hinge and extraposition bolt. One fold person door, size is 1800mmx750mm, with mechanical pressure lock and 5mm glass window. |
|
Ventilation System |
2x4kw YDW4.5L centrifugal fans for supplying, air capacity is 26000m3/h; 1x5.5kw YDW5.6S centrifugal fan for exhausting, air capacity is 15000m3/h. Pneumatic damper. The frame is soldered by 50mmx50mm square tube and with powder coating. The surface sealing plate is made of =0.8mm galvanized steel and with 30mm rockwool inside. |
|
Ceiling |
Air plenum chamber made by light-weight steel structure, frame is soldered by 40mmx60mm square tube; filter frame groove is bending with =1.0mm galvanized steel with powder coating; ceiling filter bracket is made of machining concave steel pipe and ø6 round pipe with powder coating. |
|
Lighting System |
4 tubes x 8 teams x 36w famous brand lights with electric ballast, top lighting way installed with 45 degree angle, to ensure no double image and blind area, illuminance1000Lux. 20pcsx30w side lights in vertically embedded into the wall. The protection glass is 5mm white glass. And the box is bending by =0.8mm galvanized steel with powder coating. |
|
Heating System |
Italy Riello G20 diesel burner, 200000Kcal/h. Heating exchanger is made of =1.5mm sus304 stainless steel by argon arc welding. |
|
Purification System |
Prefilter is using non-woven filter cotton; ceiling filter is using CC-600G high effeicient filter, thickness 25mm, flame retardant glass is F5. The floor filter is using filter felt for paint mist.And M type active carbon for the waste gas. |
|
Electric Controlling System |
High quality electronic elements, multi-protection for the main circuit; temperature and time setting switch, spray & baking switch, light switch, emergency stop, breakdown alarm, etc. |
|
FOB QINGDAO |
USD 6400 |
More Than 90% Of Our Spraying Booth Is Customized.
1. We can design the machines according your requirements. At the same time, our engineers will give you our professional suggestions.
2. We can give you free technical support and consultation such as design your factory, make the factory layout drawing and so on.
After-sales service
1. Our fast and professional after service engineer team can go to your factory and install the machine, give you the operating guidance, and train your employees until they can operate the machine well.
2. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.
3. We provide 2 years warranty.
Captain Advantages
*The same price higher quality, the same quality lower price! ! !
*2 years quality warranty! ! !
*Fast and stable supply capability! ! !
*Personalized design to meet customer various needs! ! !
Competitive Price and High Quality Spraying Booth with Perfect Service Is From Here.
