Model NO.
EZ-YC 100R
Sketch |
|
|
Outside Size(mm) |
7000x5350x3300 |
Inside Size(mm) |
6900x3900x2650 |
Front Door(mm) |
3000x2600(WxH) |
Total Power |
8kw |
|
Basement |
=0.8mm galvanized steel for bottom coaming, the floor beam is made of galvanized square tube whose specification is 40mmx80mmx1.5mm; 3 rows of diamond plate, 2 rows of grilles which is made of 30mmx4mm flat steel, then paint. =2.5mm diamond steel plate to make 2 embossed steel ramp, 1 piece stairs. The whole structure is strong, durable and beautiful. |
|
Cabin System |
50mm EPS panel, double 0.326mm steel with tongue and groove structure. The main door is without aluminum side cover, produced by one-time suppress. The watching window is with 5mm white glass. Aluminum alloy hinge and extraposition bolt. One fold person door, size is 1800mmx750mm, with mechanical pressure lock and 5mm glass window. |
|
Ventilation System |
2 sets 3kw YDW4.5L centrifugal fans for supplying, air capacity is 22000m3/h; The frame is soldered by 50mmx50mm square tube and with powder coating. The surface sealing plate is made of =0.8mm galvanized steel and with 30mm rockwool inside, electrical or pneumatic damper, equiped with 10N Holland electrical or pneumatic actuator. |
|
Ceiling |
Air plenum chamber made by light-weight steel structure, frame is soldered by 40mmx60mm square tube; filter frame groove is bending with =0.8mm galvanized steel with powder coating; ceiling filter bracket is made of machining concave steel pipe and ø6 round pipe with powder coating. |
|
Lighting System |
4 tubes x 8 teams x 36w famous brand lights with electric ballast, top lighting way installed with 45 degree angle, to ensure no double image and blind area, illuminance800Lux. The protection glass is 5mm white glass. And the box is bending by =0.8mm galvanized steel with powder coating. |
|
Heating System |
Italy Riello G20 diesel burner, 200000Kcal/h. Heating exchanger is made of =1.2mm sus304 stainless steel by argon arc welding. |
|
Purification System |
Prefilter is using non-woven filter cotton; ceiling filter is using CC-600G high effeicient filter, thickness 25mm, flame retardant glass is F5. The floor filter is using filter felt for paint mist. |
|
Electric Controlling System |
High quality electronic elements, multi-protection for the main circuit; temperature and time setting switch, spray & baking switch, light switch, emergency stop, breakdown alarm, etc. |
|
Optional |
Wall Panel |
50mm rock wool panel, with double steel 0.376/0.426mm steel, density is 100kgs |
|
Side Lights |
20pcsx30w in vertically embedded into the wall. The light box is with powder coating. |
|
Environmental Cabin |
1x4kw centrifugal fan with floor filter and active carbon filter. in Draw-out type plate structure |
|
FOB QINGDAO |
USD 5900 |
