Wooden Pellet Machine

Wooden Pellet Machine

Application:  Wooden Pellet Machine High ...

Market Type:  After Market

Packing:  Pallet

Samples:  Free

Maximum Prodcution Capacity:  1000-2000pieces/Month

Delivery Time:  In Accoring To The Order Of Client

Place of origin:  China

Export Ratio:  91% - 100%

Minimum Order:  1Piece/Pieces

Product Attribute:

Applicationt:

Wooden Pellet Machine High Efficiency Woolen Pellet Machine Best Wood Granulator Product detail Wooden pellet machine has a high efficiency, stable and lower-maintenance and the life span of machine is over than 10 years. You choosed us to choose the quality assurance and reasonable price. Pellet machine Parameter Screw feeder Conditioner Diameter 245mm Diameter 400mm Motor power 2.2KW(3MP) Length 1830mm Flow rate 5.27Cubic dm (R Volume 360 Cubic dm Speed 0-158Rpm Motor power 5.5KW Main Motor Ring Die Main motor power 160KW(220Mp) Inner diameter 520mm Pulley diameter 1100mm Working width 82mm Ring die rotate speed 6M)

Production Description:

Wooden Pellet Machine High Efficiency Woolen Pellet Machine
Best Wood Granulator
Product detail
Wooden pellet machine has a high efficiency, stable and lower-maintenance and the life span of machine is over than 10 years.
You choosed us to choose the quality assurance and reasonable price.


Pellet machine Parameter
Screw feeder Conditioner
Diameter 245mm Diameter 400mm
Motor power 2.2KW(3MP) Length 1830mm
Flow rate 5.27Cubic dm/R Volume 360 Cubic dm
Speed 0-158Rpm Motor power 5.5KW
Main Motor   Ring Die
Main motor power 160KW(220Mp) Inner diameter 520mm
Pulley diameter 1100mm Working width 82mm
Ring die rotate speed 6M/S Total width 182mm
Belt type 5V-1700/1900 Working area 13.93 Cubic dm
Roller Shell   Weight
Number of Rollers 2 pcs Main machine weight 5972Kgs
Outer diameter of  Rollers 250mm Screw feeder
+Conditioner
990Kgs
    Total weight 6960 Kgs
