Decoiler Straightener & Servo Feeder NCLB-300

Product Attribute:

Applicationt:

cadillac

Production Description:

Decoiler straightener & servo feeder NCLB-300 (metal thickness 0.3mm-2.2mm)


High Performance, Space Saving Combination
decoiler, leveler & servo feeder is designed to decoil while holding coil & feed the material with a combination feeder / leveler. Simple operation with safety, easy maintenance, and efficient automatic feeding with better accuracy. Coil thicknesses up to 2.2mm can be processed & coil weights up to 3T can be processed.

Standard feature for Decoiler straightener & servo feeder
1. Electric eye loop control system
2. All rollers for sraightener and feeder are quenched and hard chromed plated
3. Feeding level easily adjusted by advance worm gear screw device.
4. PLC control feeding program from Mitsubishi.
5. Hold down arm for decoiler
6. Air pressure disc braking device
7. Variable frequency adjustable speed for uncoiler

Optional feature for Decoiler straightener & servo feeder
1. Hydraulic mandrel expansion
2. Feeding level adjustable by electromotion
3. Hydraulic coil car
4. Motorized feeding level adjustment
5. Motorized breaker roll adjustment

Decoiler straightener & servo feeder specs:

Model	NCLB-300	NCLB-400	NCLB-500	NCLB-600
Coil thickness (mm)	0.3-2.2
Coil width (mm)	75-300	75-400	75-500	75-600
Max. coil weight (kg)	2000(3000)		3000(5000)
Coil O.D. (mm)	1200(1500)
Coil I.D. (mm)	508
Max. working speed (m/min)	24
Leveling roll	Upper 4/lower 3		Upper 5/lower 4
Feeding roll (set)	1
Servo motor	AC1.8
Uncoiler expansion	Hydraulic
Uncoiler motor	AC 0.75		AC 1.5
Air pressure (MPa)	5


Leveling capacity:

Model/width/thickness	0.3	0.6	1	1.2	1.4	1.6	2	2.2
NCLB-300	300							220
NCLB-400	400						280	210
NCLB-500	500					390	250	200
NCLB-600	600				400	300	240	180


Note: The data above is for your reference only, if any changes without notice.
