Input Voltage:5.0v
OutputVoltage:0.51-4.85v
Current:0.001A
Resistive:50Ω
Output:Analog signal
Size:30*20*12mm
Weight:20g
Color:Black
Temperature accuracy:2%
R25:2000om
Acura, BMW, Daihatsu, Ferrari, fiat, Ford, Mitsubishi, volvo
OE reference number: 21605577-2A / DELPHI No: 12232201 APPLICATION : Mitsubishi , FlyerDELPHIModel 621: Temperature Manifold Air Pressure(TMAP) FEATURES 2.9 psia to 14.8 psia; 20 KPa to 102 KPa; 0.2 bar to 1.0 bar 1.5FS Static Accuracy MEMS technology Programmable ASIC to meet customer specifications Low part count enhances reliability Amplified and temperature compensated EMI protection Combination of pressure and temperature sensor(MAP/MAT) MAP sensor precision with reliable thermistor outputTwo-in-one sensor yields cost reduction and space savings w/one fewer component, wire and connector DESCRIPTIONS Model 621 incorporates MEMS technology and custom Application Specific Integrated Circuit (ASIC) technology in the design. It is specifically designed for tough automotive application.The Temperature Manifold Air Pressure sensors in Model 621 provide tow separate outputs critical to air/fuel ratio optimization: One voltage output proportional to engine intake manifold pressure One resistance output proportional to manifold air temperatureModel 621 is designed to perform in the underhood harsh environment such as temperature extremes, vibration, thermal and mechanical shock, and corrosive chemical. Please contact us for special design to meet your requirements.
