Applicationt:
Toyota ( Previa)
Toyota ( Rav4, Prado, Hiace)
Production Description:
Feature & Structure:
*1) multi-ribs of insulator eliminate flashover
*2) insulator made of 95% pure alumina, strong resistant of heat shock, great mechanic and electrical features, super insulation.
*3) nickel plated housing prevents oxidation and corrosion, heat crimping process ensures absolute gas-tight fit.
*4) inner sealing with conductive glass ensures a fine conductivity and sealing.
*5) multi-layer gaskets are elastically strong, and reliable in sealing.
*6) Cooper core electrode prevents oxidation and corrosion, good electric and heat conductivity, long spark plug service life.
The following specifications for choosing:
* Type of seat & thread
Thread specifications: M10x1, M12x1.25, M14x1.25, M18x1.5
Thread length: 7.8mm, 9.5mm, 10.9mm, 11mm, 12mm, 12.7mm, 19mm, 25mm, 26.5mm
Hex: 16 / 17.5 / 19 / 20.8 / 25.4
Gap: 0.6mm, 0.7mm, 0.8mm, 0.9mm, 1.0mm
* Heat range: from 1 to 12.
Instructions: we set the heat range from 1 to 12, and higher the index, cooler the plug.
* Version:
Resistor: Projective 0.5~2 / Projective 2~4 / Projective 4~7 / V-grooved central electrode / Round ground side electrode
* Side electrode structure: Two-electrode / Three-electrode / Four-electrode
* Electrode material: Super-electrode / Platinum electrode / Top electrode
* Ignition gap:
0.9mm, 1.0mm, 1.1mm, 1.3mm, 1.5mm, 2.0mm
Other quick details:
Name: spark plug
type/model:
brand: ansiauto
OE no.: car mark:
Place of origin: Ningbo, China.
Packing and delivery:
Single packing, 10pcs/color box, 400pcs/carton
Carton dimension:
Blister card packing: 40x35x24cm
Box packing: 36x24x27cm
Delivery time: within 25days
Mini order: 10,000pcs
2,000,000.pcs monthly capacity
