Diesel Injection Pump Test Bench 18.5 KW (25HP) AC

Application: Universal

Market Type: After Market

Samples: Not Available

Export Ratio: 71% - 80%

Unit Price: USD 9500

Price Terms: FOB

Payment Terms: T/T

Minimum Order: 1

Language Translator

Applicationt:

Universal

Production Description:

18.5 KW (25HP) AC high torque motor.

Industrial fan les PC with Windows TM Professional operating system fully integrated 15'' XGA 450 nits TFT-LCD sunlight readable (for easy reading).

Anti Backlash coupling.

Two DC supply 12-24 Volts 3 Amps.

Pressure phasing to 80 Bar.

Fully automatic Fuel Temperature Control System.

Direct Drive System- DDS.

Forced lubrication pump oil to 30 Bar.

Analogue speed potentiometer for manual speed control.

Digital speed control system provides smooth speed control between 0-4000 rpm via a multi turn precision speed control knob.

Data base system management for test plan/customer records.

12 cylinders low volume / high volume glass reading deliveries for easy operating.

Display of main features of test bench operating parameters via 15'' TFT/LCD.

Electronic Feedback System prevents speed changes in load variances by monitoring the speed and load relation during the entire run time.

Larger flywheel inertia provides more stable speed Control.

New measuring console with two axis of motion.

New control panel provides for a user friendly operation.

Well tooled standard accessory package for most common Rotary and Inline pumps.

Sophisticated NEW design
The ADM720 will create a new image of your workshop with its design and colours and provide you the best operating, friendlier and ergonomically designed environment.

Anti-backlash coupling
The Anti-Backlash coupling ensures the safety of the test bench operator with its durable and strong design and provides reliable testing of the new technology high-pressure fuel injection pumps.

The flywheel
Directly mounted on the motor shaft and with 1,0 kgm² inertia provides a smooth drive of even the toughest cam profiles, and absorbs the impact of the new pumps. The test results obtained are therefore much more reliable and accurate comparing with smaller flywheel drive systems.
