4G/LTE FPC Internal Antenna

4G/LTE FPC Internal Antenna

Application:  Applications: GSM ( CDMA ...

OEM No/Model:  AC-Q7027-N21

Market Type:  After Market

Packing:  20 Pcs/Carton

Samples:  Charge

Maximum Prodcution Capacity:  1000000 PCS/Year

Delivery Time:  3-5 Days After Payment

Place of origin:  CHN

Export Ratio:  71% - 80%

Unit Price:  USD 1-1.2

Price Terms:  EXW

Delivery Port:  GZ

Other Price Terms:  FOB GZ

Minimum Order:  1Piece/Pieces

Product Attribute:

Applicationt:

Applications: GSM ( CDMA mobile terminal design frequency communication vehicle of a medium-gain Car Antenna. Car Antenna paste method uApplications: GSM )

Production Description:

1. Introduction

All band frequency from 824-960MHz / 1710-2700MHz.

Antenna is flexible and robust.

Its slim-line design allows for covert and convenient installation in the device, its

It is a high gain, high efficiency solution which antenna cables and connectors are

fully customizable.






Electrical

fully customizable.  824-960/1710-2700MHz
Band width   136/990MHz
Gain  2.3/3dBi
V.S.W.R  ≤3.0
Radiation  -
Polarization  Linear
Lightning Protection -
Maximum Input Power  50W
Impedance 50
Connector  IPEX
Cable Type 1.13cable
Cable Length 10cm
Antenna Radome Material FPC
Mount way  Adhesive
Mechanical
Dimensions 106.7x13MM
Weight 8g
Operating Temperature -40 to+70
Humidity +15-70%RH
RoHS Compliant YES
