Auto hub bearing DAC32700038 front wheel bearing DAC32700038 SNR NSK bearing DAC32700038
Product Description
Wheel Hub Bearing Description
Wheel bearings are used in automotive axles for load-bearing and rotating at the hub of providing precise guidance components, both axial load and radial load,this bearing is an important part of the car load and rotation.
Specifications
Product Name | automobile wheel hub bearing | ||||
Series | DAC series,etc. | ||||
Rings Material | Chrome steel-GCr15, | ||||
Cages Material | steel,brass,nylon | ||||
ID size | 10-400mm | ||||
Quality standard | ISO9001:2008 | ||||
Precsion | P0,P6 | ||||
ABEC-1,ABEC-3 | |||||
Clearance | C0,C1,C2,C3 | ||||
Noise | Z1,Z2,Z3 | ||||
Vibration | V1,V2,V3 | ||||
HRC | 58-65 | ||||
Tolerance Grade | GB/T307.1-205 |
Specifications of Auto hub bearing DAC32700038
|
|
|
|
|
|
|
|
|
|
Part No.: | Germany | Sweden | Japan | d | D | B | C | Weight(kg) | Seal |
DAC30650021 | 522372 | 630374/C4 |
| 30 | 65 | 21 | 21 | 0.27 | A |
DAC3060024 |
| 361971 |
| 30 | 67 | 24 | 24 | 0.34 | C |
DAC30680045 |
|
| 30BWD04CA19 | 30 | 68 | 45 | 45 | 0.73 | E |
DAC32700038 |
|
|
| 32 | 70 | 38 | 38 | 0.62 | E |
Features of wheel hub bearings
A. auto wheel hub bearings are adopted with international superior raw material and high-class grease from USA Shell grease.
B. The series auto wheel hub bearings are in the nature of frame structure, light weight, large rated burden, strong resistant capability, thermo stability, good dustproof performance and etc.
C. Auto wheel hub bearing can be endured bidirectional axial load and major radial load and sealed bearings are unnecessary to add lubricant additives upon assembly.
DAC series of wheel hub bearings
Bearing No. | Dimensions(mm) | Weight | Seal | ||||||
PEAK | Germany | Japan | Sweden | d | D | B | C | kg | |
DAC255200206 |
|
| 617546A | 25 | 52 | 20.6 | 20.6 | 0.19 | A |
DAC25520037 | 546467 |
| 445539AA | 25 | 52 | 37 | 37 | 0.31 | C |
DAC27600050 |
| 513071 | IR8653 | 27 | 60 | 50 | 50 | 0.56 | C |
DAC28580042 |
| DAC2858W | 28BW03A | 28 | 58 | 42 | 42 | 0.47 | C |
DAC28610042 |
| DAC286142AW |
| 28 | 61 | 42 | 42 | 0.56 | D |
DAC30600037 |
| DAC3060372RS |
| 30 | 60 | 37 | 37 | 0.42 | C |
DAC30600337 | 529891AB | DAC3060W | BA2B 633313C | 30 | 60.03 | 37 | 37 | 0.45 | C |
DAC30640042 |
| DAC3064W2RKBCS28 | 34BWD03ACA78 | 30 | 64 | 42 | 42 | 0.49 | C |
DAC30630342 |
| DAC3063W-1 |
| 30 | 63.03 | 42 | 42 | 0.54 | D |
DAC30650021 | 522372 |
| BB1B 630374/C4 | 30 | 65 | 21 | 21 | 0.27 | A |
DAC34620037 | 531910 |
| 309724 | 34 | 62 | 37 | 37 | 0.41 | C |
DAC34640034 |
| DAC3464D |
| 34 | 64 | 34 | 34 | 0.43 | D |
DAC34640037 | 532066DE | DAC3464G1 | 309726DA | 34 | 64 | 37 | 37 | 0.48 | B |
DAC34660037 | 580400CA |
| 559529 | 34 | 66 | 37 | 37 | 0.50 | C |
DAC34680037 |
| DAC3468DW |
| 34 | 68 | 37 | 37 | 0.55 | - |
DAC34680042 |
| DAC34682RS |
| 34 | 68 | 42 | 42 | 0.64 | B |
DAC35640037 |
| DAC3564A-1 |
| 35 | 64 | 37 | 37 | 0.41 | B |
DAC35650035 | 546238A | DAC3565WCS30 | BT2B 445620B | 35 | 65 | 35 | 35 | 0.40 | C |
DAC35660032 |
|
| 445980A | 35 | 66 | 32 | 32 | 0.42 | C |
DAC35660033 |
|
| BAHB 633676 | 35 | 66 | 33 | 33 | 0.43 | C |
DAC35660037 | 546238 |
| BAHB 311309 | 35 | 66 | 37 | 37 | 0.48 | C |
DAC35680037 | 567918B | DAC3568A2RS | BAHB 633528F | 35 | 68 | 37 | 37 | 0.52 | C |
DAC35680233/30 |
| DAC3568W-6 |
| 35 | 68.02 | 33 | 30 | 0.47 | D |
DAC35720228 | 544033 |
| BA2B 441832AB | 35 | 72.02 | 28 | 28 | 0.49 | D |
DAC35720033 | 548083 |
| BA2B 446762B | 35 | 72 | 33 | 33 | 0.58 | C |
DAC35720034 | 540763 | DAC357234A | 35BWD01CCA38 | 35 | 72 | 34 | 34 | 0.58 | A.D |
DAC35720233/31 |
| DAC357233B-1W | 35BWD06ACA111 | 35 | 72.02 | 33 | 31 | 0.56 | D |
DAC35720433 |
|
| BAHB 633669 | 35 | 72.04 | 33 | 33 | 0.58 | C |
DAC35720045 |
| DAC357245CW2RS |
| 35 | 72 | 45 | 45 | 0.63 | C |
DAC35800045 |
| DAC3580W-3HR4 |
| 35 | 80 | 45 | 45 | 1.10 | - |
DAC36650037 |
| DAC3665W |
| 36 | 65 | 37 | 37 | 0.45 | D |
