Quick Details

• Place of Origin:

  China

• OE Experience:

  No

Product Name:Thin Section Bearing

Thin Section Bearing

Application

None

Product Description:

Thin section bearings have high precision, are very quiet and have high load carrying capacity. These ball bearings are available in three different designs and have an extremely small, predominantly square cross-section. Within each series, the cross-section remains constant even for larger shaft diameters and housing bores. The bearings are therefore also described as Constant Section (CS). This special feature distinguishes thin section bearings from conventional bearings as standardised in ISO series.
It is therefore possible to select a larger cross-section and thus use a bearing with higher load carrying capacity without the need to change the shaft diameter as well. Thin section bearings allow designs to be achieved that are extremely light and require little space.
Thin section bearings are available as deep groove ball bearings (C), four point contact bearings (X) and angular contact ball bearings (E). Each of these designs is available in various series. The series correspond to the cross-section sizes. The balls are matched to the series.
Deep groove ball bearings can support axial loads from both directions as well as radial loads.
Four point contact bearings can support axial loads from both directions as well as radial loads; they thus act in the same way as double row angular contact ball bearings.
Angular contact ball bearings can be filled with an optimised number of balls and have a contact angle of 30°. They can support considerably higher radial loads than deep groove ball bearings or four point contact bearings are can support axial loads from one direction. For special requirements, angular contact ball bearings are also available as matched bearings. These combinations then have a significantly higher rigidity and load carrying capacity than single bearing solutions.

Below are some of the part numbers we are offering:

HKAA010C, HKAA015C, HKA020C, HKA025C, HKA030C, HKA035C, HKA040C,HKA042C, HJHA010X, HJHA015X, HJA020X, HJA025X, HJA030X, 61800, 61801, 61802, 61803, 61900, 61901, 61902, 61903.

We Hubei Parts Service Supply Co., Ltd -------One of the professional bearings supplier in China. When we first start our business, we have set up a goal to become a leader in providing excellent customer service and superior quality products with perfect prices to the global market. The ...[Read More]

Company Profile:

• Main Product:

  Bearings

• Business Type:

  Trading Company

• Current Export Market:

  North America, South America, Western Europe, Eastern Europe, Eastern Asia

Factory Profile:

• Number of Employees:

  51 - 100 People
