OEM No/Model: 8481.80.9005
Intrinsic safety explosion barrier is an explosion-proof device with single channel, Zener-diode DC circuit that enables interactive electric signaling without short circuit while controlling energy transmission in order to prevent ignition in explosive atmosphere.
1.Applicable to Zone 0.
2.A-class ground is not necessary since the input and output are insulated
each other.
3.When serially connected to a transmission circuit, the barrier protects
the circuit and components in hazardous area from being affected by
a serious accident in the non-hazardous area.
4.Despite in the hazardous location, conventional wiring is available.
5.Intrinsical proof of operational signal is figured out easily and at lower
cost.
6.SAF100-5 safety barrier employ crimping terminal wiring method.
7.As SAF100-5 safety barrier has protection circuit, it will be not broken
if you wired in the wrong polarity.
8.LED indicates the condition of the input and output
Model code | 100-5 |
Explosion-proof construction | Intrinsic safety constructionEC) |
Rated voltage | 24±10% |
Maximum voltage of a intrinsic safety circuit | 29.4 |
Max. allowable voltage | 25.95 |
Maximum current of a intrinsic safety circuit | 93.8 |
Electric power of a intrinsic safety circuit | 0.689W |
Ambient temp. | -2050 |
Basic circuit figure |
Does not need A-class ground. |
Operating condition |
1.Place the valve in non-hazardous area. 2.Perform single grounding using type A ground. 3. Parts and connections cannot be changed. 4. Use with specified solenoid valves. 5. Allowable inductance for external connection: 2mH / Capacitance: 0.05 μF |
