Type |
GJXCH-1B1 (or B6a, B6b) GJXCH-2B1 (or B6a, B6b) GJXCFH-4B1 (or Ba, Bb) |
|||||
Applications |
Applied to FTTH, FTTO and FTTB with messenger |
|||||
Product description |
A butterfly lead-in cable has the fiber unit at the center. Two parallel metallic or non-metallic strength members are positioned in each one side of the fiber unit. The whole assembly is then extruded with black or white sheath of LSZH,PE or PVC. |
|||||
Features |
1 G657 ensures good bending performance, secures network transmission; |
|||||
2 simple structure, light weight and high practicability; |
||||||
3 two parallel steel wires, as strength member, provides good performance of crush and tension resistance to protect the fiber; |
||||||
4 novel flute design, easily strip and splice, simplify the installation and maintenance; |
||||||
5 low smoke zero halogen and flame retardant sheath, safe and environmentally friendly; |
||||||
Dimensions |
2.0×3.0mm |
|||||
Attenuation indicators |
Wavelength |
B1.1 B1.3(G652) |
B6a(G657A) |
B6b(G657B) |
||
1310nm |
0.45dB/Km |
0.45dB/Km |
0.60dB/Km |
|||
1550nm |
0.30dB/Km |
0.30dB/Km |
0.50dB/Km |
